BCS Line User Manual page 136

125
Step 2 In the Channel list, select a channel that you want to configure face detection
function.
Step 3 In the Type list, select AI by Reorder or AI by Camera as needed.
When AI by Camera is selected, you can enable Face Enhancement function to
improve face detection efficiency.
Step 4 Configure the parameters. See Table 4-35.
Parameter
Enable
Rule
Schedule
Alarm-out Port
Post-Alarm
Copyright © NSS Sp. z o.o.
Figure 4-136
Table 4-35
Description
Click to enable or disable the face detection.
Click Setting to draw areas to filter the target.
You can configure two filtering targets (maximum size and
minimum size). When the target is smaller than the minimum
size or larger than the maximum size, no alarms will be
activated. The maximum size should be larger than the
minimum size. Left click to drag the four angles to adjust the
size.
Configure the period and in the set time range, the
corresponding configuration item will be linked to start the
alarm.
The alarm device (such as lights, sirens, etc.) is connected to
the alarm output port. When an alarm occurs, the NVR device
transmits the alarm information to the alarm device.
When the alarm ends, the alarm extended for a period of time.
The time range is from 0 seconds to 300 seconds.
125
User's Manual
