BCS Line User Manual page 191

User's Manual
Parameter
Report Alarm
Send Email
Record Channel
Post-Record
PTZ Linkage
Tour
Picture Storage
Buzzer
Alarm Tone
Step 3 Click Apply to save the settings.
Description
Select the check box. When an alarm occurs, the NVR device uploads
an alarm signal to the network (including the alarm center).
● This function is for some series products only.
● You need to set the alarm center first. For details, see "1.11.13
Alarm Center".
Select the check box. When an alarm occurs, the NVR device sends an
email to the set mailbox to notify the user.
You need to set the email first. For details, see "1.11.10 Email".
Select the check box and select the needed recording channel (support
multiple choices). When an alarm occurs, the NVR device activates the
channel for recording.
You need to enable intelligent recording and auto recording first. For
details, see "1.1.4.6 Schedule".
At the end of the alarm, the recording extends for a period of time. The
time range is from 10 seconds to 300 seconds.
Select the check box and click Setting to select the channel and PTZ
action. When an alarm occurs, the NVR device associates the channel
to perform the corresponding PTZ action. For example, activate the PTZ
in channel one to turn to the preset point X.
● Tripwire alarm supports to activate PTZ preset point only.
● You need to set the corresponding PTZ actions first, see "1.4.4
Calling PTZ Functions".
Select the check box and select the channel for tour. When an alarm
occurs, the local interface of the NVR device displays the selected
channel screen.
● You need to set the time interval and mode for tour first, see "1.16.2
Tour".
● After the tour is over, the preview interface is restored to the screen
split mode before the tour.
Select the Snapshot check box to take a snapshot of the selected
channel.
To use this function, select Main Menu > CAMERA > Encode >
Snapshot, select Event in Type list.
Select the check box to activate the buzzer when an alarm occurs.
Check the box and then select the corresponding audio file from the
drop-down list. System plays the audio file when the alarm occurs.
Refer to "1.17.1 File Management" to add audio file first.
180
