BCS Line User Manual page 104

93
The following figure is for reference only.
No. Function
1 Display Window
Playback Controls
Bar
2 Clip
Backup
Copyright © NSS Sp. z o.o.
Figure 4-102
Table 4-28
Description
Display the searched recorded video or picture. It
supports playing in single-channel, 4-channel, 9-channel,
and 16-channel simultaneously.
When playing back in a single channel mode, hold down
the left mouse button to select the area that you want to
enlarge. The area is enlarged after the left mouse button
is released. To exit the enlarged status, right-click on the
image.
Playback control buttons. Refer to "1.6.2.1 Playback
Control" for detailed information.
Click to edit the record file and then save specified
footages. Refer to "1.6.2.3 Clip" for detailed information.
Click to backup record. Refer to "1.6.2.4 Record
Backup" for detailed information.
93
User's Manual
