User's Manual
Step 2 To configure the settings for the tampering detection parameters, see "1.8.5.1 Motion
Detection".
The Tampering function does not have region and sensitivity items.
Step 3 Click Apply to complete the settings.
● Click Default to restore the default setting.
● Click Copy to, in the Copy to dialog box, select the additional channel(s) that you
want to copy the motion detection settings to, and then click Apply.

1.8.5.3 Video Loss

When the video loss occurs, the system activates the alarm.
Step 1 Select Main Menu > ALARM > Video Detection > Video Loss.
The Video Loss interface is displayed. See Figure 4-195.
Figure 4-194
184
