BCS Line User Manual page 208

197
Step 2 Configure the settings for the POS parameters. See Table 4-62.
Parameter
POS Name
Enable
Record Channel
Privacy
Protocol
Connection
Mode
Character
Encode
Copyright © NSS Sp. z o.o.
Figure 4-204
Table 4-62
Description
In the POS Name list, select the POS machine that you want to
configures settings for. Click
● The POS name shall be unique.
● The POS name supports 21 Chinese characters or 63 English
characters.
Enable the POS function.
Click to select a channel to record.
Enter the privacy contents. Refer to "1.9.2.1 Privacy Setup".
Select POS by default. Different machine corresponds to different
protocol.
In the Connection Mode list, select the connection protocol type. Click
, the IP Address interface is displayed.
In the Source IP box, enter the IP address (the machine that is
connected to the Device) that sends messages.
Select a character encoding mode.
197
to modify the POS name.
User's Manual
