1.13.2 RS232

After setting RS-232 parameters, the NVR can use the COM port to connect to other device to
debug and operate.
Step 1 Select MAIN MENU > SYSTEM > RS232.
Step 2 The RS232 interface is displayed. See Figure 4-264.
Step 3 Configure parameters. See Table 4-83.
Parameter
Function
Baud Rate
Data Bits
Stop Bits
Parity
Step 4 Click Apply.

1.14 Security

You can set security options to strengthen device security and use the device in a much safer
way.
1.14.1 Security Status
Copyright © NSS Sp. z o.o.
Figure 4-264
Table 4-83
Description
Select serial port control protocol.
● Console: Upgrade the program and debug with the console and
mini terminal software.
● Keyboard: Control this Device with special keyboard.
● Adapter: Connect with PC directly for transparent transmission
of data.
● Protocol COM: Configure the function to protocol COM, in order
to overlay card number.
● PTZ Matrix: Connect matrix control
Different series products support different RS232 functions. The
actual product shall prevail.
Select Baud rate, which is 115200 by default.
It ranges from 5 to 8, which is 8 by default.
It includes 1 and 2.
It includes none, odd, even, mark and null.
