User's Manual
This function is for some series products only.
Step 1 Select Main Menu > SEARCH.
The SEARCH interface is displayed.
Step 2 In the Search Type list, select Subperiod; In the Split Mode list, select 4, 8, or 16. See
Figure 4-111.
Step 3 In the Calendar area, select a date.
Step 4 In the Camera Name list, select a channel.
Only single-channel supports this function.
Step 5 Start playing back splices. See Figure 4-112.
Click
Double-click anywhere on the time bar, the playback starts from where you click.

1.6.8 File List

Click , system displays file list. It displays the first channel of the record. See Figure 4-113.
Figure 4-111
, the playback starts from the beginning.
Figure 4-112
102
