People Counting - BCS Line User Manual

149
Parameter
Voice Prompts
Buzzer
Step 3 Click Apply to complete the setup.

1.7.2.7 People Counting

System adopts video image and graphics analysis technology. System can calculate the
entry/exit people amount in the specified zone on the video. It can generate an alarm when the
amount has exceeded the threshold.
1.7.2.7.1 People Counting
Step 1 Select Main Menu > AI > Parameters > People Counting > People Counting.
The People Counting interface is displayed. See Figure 4-161.
Step 2 Draw people counting rule.
1) Click
2) Configure parameters.
Parameter
Name
Duration
Copyright © NSS Sp. z o.o.
Description
Check the box and then select the corresponding audio file from the
dropdown list. System plays the audio file when the alarm occurs.
Refer to "1.17.1 File Management" to add audio file first.
Select the check box to activate the buzzer when an alarm occurs.
Figure 4-161
to draw people counting rule.
Table 4-47
Description
Customize the rule name.
Set the minimum time that the object stays until the alarm is
triggered.
149
User's Manual
