Smd - BCS Line User Manual

157
Parameter
Voice Prompts
Buzzer
Step 5 Click Apply.

1.7.2.10 SMD

You can use SMD (Smart Motion Detection) to detect human and vehicle in the video, and sore
the detection result in structured storage for fast retrieval.
Step 1 Select Main Menu > AI > Parameter > SMD.
Step 2 Select and enable a channel, and then configure parameters.
Parameter
Sensitivity
Effective Target
Schedule
Anti-Dither
Copyright © NSS Sp. z o.o.
Description
Check the box and then select the corresponding audio file from the
dropdown list. System plays the audio file when the alarm occurs.
Refer to "1.17.1 File Management" to add audio file first.
Select the check box to activate the buzzer when an alarm occurs.
Figure 4-166
Table 4-51
Description
The higher the value is, the easier it is to trigger an alarm. But at
the same time, the false alarm may occur. The default value is
recommended.
Choose human or vehicle or both.
Configure the period and in the set time range, the corresponding
configuration item will be linked to start the alarm.
Indicates the time taken from the end of motion detection to the
end of alarm linkage action. The range is 0 to 600 seconds.
157
User's Manual
