1.11.7 PPPoE
PPPoE is another way for the Device to access the network. You can establish network
connection by configuring PPPoE settings to give the Device a dynamic IP address in the WAN.
To use this function, firstly you need to obtain the user name and password from the Internet
Service Provider.
Step 1 Select Main Menu > NETWORK > PPPoE.
The PPPoE interface is displayed. See Figure 4-231.
Step 2 Enable the PPPoE function.
Step 3 In the User Name box and Password box, enter the user name and password
accordingly provided by the Internet Service Provider.
Step 4 Click Apply to complete the settings.
The system pops up a message to indicate the successfully saved. The IP address
appears on the PPPoE interface. You can use this IP address to access the Device.
When the PPPoE function is enabled, the IP address on the TCP/IP interface cannot
be modified.

1.11.8 DDNS

When the IP address of the Device changes frequently, the DDNS function can dynamically
refresh the correspondence between the domain on DNS and the IP address, ensuring you
access the Device by using the domain.
Background Information
Ensure the Device supports the DDNS Type and log in the website provided by the DDNS
service provider to register the information such as domain from PC located in the WAN.
After you have registered and logged in the DDNS website successfully, you can view the
information of all the connected devices under this user name.
Step 1 Select Main Menu > NETWORK > DDNS.
The DDNS interface is displayed. See Figure 4-232.
