1.2.5.2 Privacy Masking

You can set the privacy masking area on the screen to guarantee the privacy of the area.
Step 1 Select Main Menu > CAMERA > Overlay > Privacy Masking.
Step 2 Configure parameters.
Parameter
Channel
1, 2, 3, 4
Default
Step 3 Click Apply.

1.2.6 Encode

You can set video bit stream and image parameters.
Copyright © NSS Sp. z o.o.
Figure 4-56
Table 4-15
Description
Select a channel.
Select Enable to enable privacy masking. The number
represents the number of masking areas. You can select a
number and drag masking areas to the screen, and you can
also change the size of areas or drag an area to other place.
You can drag up to 4 masking areas to one channel.
Set as device default configuration.
