User's Manual
Parameter
Encryption Type
Step 3 Compile the two MIB files by MIB Builder.
Step 4 Run MG-SOFT MIB Browser to load in the module from compilation.
Step 5 On the MG-SOFT MIB Browser, enter the Device IP that you want to manage, and
then select the version number to query.
Step 6 On the MG-SOFT MIB Browser, unfold the tree-structured directory to obtain the
configurations of the Device, such as the channels quantity and software version.

1.11.12 Multicast

When you access the Device from the network to view the video, if the access is exceeded, the
video will not display. You can use the multicast function to group the IP to solve the problem.
Step 1 Select Main Menu > NETWORK > Multicast.
The MULTICAST interface is displayed. See Figure 4-237.
Step 2 Configure the settings for the multicast parameters. See Table 4-75.
Parameter
Enable
IP Address
Port
Step 3 Click Apply to complete the settings.
Description
In the Encryption Type list, select an encryption type. The default
setting is CBC-DES.
Figure 4-237
Table 4-75
Description
Enable the multicast function.
Enter the IP address that you want to use as the multicast IP.
The IP address ranges from 224.0.0.0 through 239.255.255.255.
Enter the port for the multicast. The port ranges from 1025 through
65000.
232
