BCS Line User Manual page 61

User's Manual
Step 2 Configure parameters. See Table 4-13.
Different series network camera displays different parameters. The actual product
shall prevail.
Parameter
Channel
Profile
Brightness
Contrast
Saturation
Figure 4-55
Table 4-13
Description
In the Channel list, select the channel that you want to configure.
There are three config files for you. System has configured the
corresponding parameters for each file, you can select according
to your actual situation.
Adjusts the image brightness. The bigger the value is, the brighter
the image will become. Adjusts the brightness according to actual
environment.
Adjusts the image contrast. The bigger the value is, the more
obvious the contrast between the light area and dark area will
become. Adjusts the contrast according to actual environment.
Adjusts the color shades. The bigger the value, the lighter the
color will become. Adjusts the saturation according to actual
environment.
