BCS Line User Manual page 40

29
2. Configure parameters. See Table 4-8.
Parameter
Channel
Manufacturer
IP Address
TCP Port
User Name
Password
Remote CH No.
Decoder Strategy
Protocol Type
Copyright © NSS Sp. z o.o.
Figure 4-30
Table 4-8
Description
In the Channel list, select the channel that you want use on the
Device to connect the remote device.
In the Manufacturer list, select the manufacturer of the remote
device.
In the IP Address box, enter the IP address of remote device.
The default is 192.168.0.0 which the system cannot connect to.
The default value is 37777. You can enter the value as needed.
Enter the user name of the remote device.
Enter the password of the user for the remote device.
Enter the remote channel number of the remote device that you
want to add.
In the Decoder Strategy list, select Default, Realtime, or
Fluent.
● If the remote device is added through private protocol, the
default type is TCP.
● If the remote device is added through ONVIF protocol, the
system supports Auto, TCP, UDP, or MULTICAST.
● If the remote device is added through other manufacturers,
the system supports TCP and UDP.
29
User's Manual
