BCS Line User Manual page 263

User's Manual
Step 2 Configure the settings for the FTP settings parameters. See Table 4-81.
Parameter
Enable
FTP type
Server Address
Port
Anonymous
User Name
Password
Storage Path
Figure 4-262
Table 4-81
Description
Enable the FTP upload function.
● Select FTP type.
● FTP: Plaintext transmission.
● SFTP: Encrypted transmission (recommended)
IP address of FTP server.
● FTP: The default is 21.
● SFTP: The default is 22.
Enter the user name and password to log in to the FTP server.
Enable the anonymity function, and then you can login anonymously
without entering the user name and password.
Create folder on FTP server.
● If you do not enter the name of remote directory, system
automatically creates the folders according to the IP and time.
● If you enter the name of remote directory, the system creates the
folder with the entered name under the FTP root directory first, and
then automatically creates the folders according to the IP and time.
