181
● Click Default to restore the default setting.
● Click Copy to, in the Copy to dialog box, select the additional channel(s) that you
want to copy the motion detection settings to, and then click Apply.
● Click Test to test the settings.

1.8.5.1.1 Setting the Motion Detection Region

Step 1 Next to Region, click Setting.
The region setting screen is displayed.
Step 2 Point to the middle top of the interface.
The setting interface is displayed. See Figure 4-191.
Step 3 Configure the regions settings. You can configure totally four regions.
● Select one region, for example, click
● Drag on the screen to select the region that you want to detect.
● The selected area shows the color that represents the region.
● Configure the parameters. See Table 4-58.
Parameter
Name
Sensitivity
Threshold
When anyone of the four regions activates motion detect alarm, the channel where
this region belongs to will activate motion detect alarm.
Step 4 Right-click on the screen to exit the region setting interface.
Step 5 On the Motion Detection interface, click Apply to complete the settings.
Copyright © NSS Sp. z o.o.
Figure 4-191
Table 4-58
Description
Enter a name for the region.
Every region of every channel has an individual sensitivity value.
The bigger the value is, the easier the alarms can be activated.
Adjust the threshold for motion detect. Every region of every channel
has an individual threshold.
181
.
