Bps - BCS Line User Manual

User's Manual
Parameter
No.
Device Name
Physical Position
Properties
Total Space
Free Space
Health Status
S.M.A.R.T
Status

1.10.2.4 BPS

Here is for you to view current video bit rate (kb/s) and resolution.
Select Main Menu > MAINTAIN > System Info > BPS, the BPS interface is displayed. See
Figure 4-210.
Figure 4-209
Table 4-63
Description
Indicates the number of the currently connected HDD. The asterisk (*)
means the current working HDD.
Indicates name of HDD.
Indicates installation position of HDD.
Indicates HDD type.
Indicates the total capacity of HDD.
Indicates the usable capacity of HDD.
Indicates the health status of the HDD.
View the S.M.A.R.T reports from HDD detecting.
Indicates the status of the HDD to show if it is working normally.
