User's Manual
Step 2 Click the LAN name that you want to view, for example, LAN1.
The system displays the information of data sending speed and receiving speed.
● System displays LAN1 load by default.
● Only one LAN load can be displayed at one time.

1.10.3.3 Network Test

You can test the network connection status between the Device and other devices.
Step 1 Select Main Menu > MAINTAIN > Network > Test.
The Test interface is displayed. See Figure 4-214.
Figure 4-213
206
