75 User's Manual
Figure 4-79
Refer to the following sheet for detailed information. See Table 4-23.
Table 4-23
Installation modes Icon Note
360°panorama original view
1 de-warp window+1 panorama stretching
2 panorama stretching view
(Wall mount)
1 360° panorama view+3 de-warp windows
(Ground mount)
1 360°panorama view+4 de-warp windows
4 de-warp windows+1 panorama stretching
1 360° panorama view+8 de-warp windows
360°panorama original view
Panorama stretching
1 panorama unfolding view+3 de-warp
windows
（Wall mount）
1 panorama unfolding view +4 de warp
windows
1 panorama unfolding view +8 de warp
windows
75
