User's Manual
Step 3 Set record type. See Figure 4-35.
● When the record type is Motion (motion detection), alarm, M&A, IVS and POS,
enable the channel record function when corresponding alarm occurs. For
example, when the alarm type is MD, select Main Menu > ALARM > Video
Detection > Motion Detection , select the record channel and enable record
function.
● When the record type is Motion (motion detection), alarm, M&A, IVS and POS,
refer to "1.8.5 Video Detection", 1.8.3 Alarm Input", "1.7.1.3 IVS" and "4.9 POS" for
detailed information.
Step 4 Set record period. It includes edit mode and draw mode. See Figure 4-39.
Figure 4-34
Figure 4-35
Figure 4-36
