Slave Device; Transfer Record - BCS Line User Manual

User's Manual

2.4.3 Slave Device

When you add the first slave device, the default IP is the device IP address that logins on the
web.
From SETTING > Cluster Service > Master Device, you can go to the following interface. See
Figure 5-7.
See "5.4.2 Master Device" to add slave device.
After you added master device and slave device , you need to enable cluster function.
Otherwise, cluster function is null. See "5.4.5 Cluster Control" for more information.

2.4.4 Transfer Record

When the master device is in malfunction and the slave device starts to record. The NVR
automatically transfers video records from slave device when the main device is working
normally. You can also manually transfer video records from slave device to the main device.
Prerequisites
The master device works normally.
Procedure
Step 1 Select SETTING > Cluster Service > Transfer Recorder.
Step 2 Click Add Task.
Step 3 Configure parameters.
Figure 5-6
Figure 5-7
