Step 2 Select the group for each HDD group, and then click Apply to save the settings.
After configuring HDD group, under the Main Stream tab, Sub Stream tab and
Snapshot tab, configure settings to save the main stream, sub stream and snapshot
to different HDD group as selected by you.

1.12.6 Disk Quota

You can allocate a fixed storage capacity for each channel through disk quota function, and
allocate the recording storage space for each channel.
● If Disk group mode selected. is shown in the interface, click Switch to Quota Mode.
● Disk quota mode and disk group mode can not be selected at the same time.
Step 1 Select Main Menu > STORAGE > Disk Quota.
Figure 4-245
