can still work until you use the web to fix manually.
During the whole process (the master device is working properly > master device is in
malfunction > master device becomes working properly again), you can use this virtual IP to
access the device all the time.
Procedure
Step 1 Log in to the web as the admin user.
Step 2 Select SETTING > Cluster Service > CLUSTER IP.
Step 3 Configure IP Address, Subnet Mask and Default Gateway.
The first IP is for cluster internal control(For interactive communications between the
master device and slave device .), the virtual IP address is for cluster external control
(For external network connection).
Step 4 Click OK.

2.4.2 Master Device

From SETTING > Cluster Service > Master Device, you can go to the following interface. See
Figure 5-4.
On this interface, you can add several master devices manually. After you enable the cluster
function, you can view device IP, work status. Click operation, you can view the connection log
of the main device.
Procedure
Step 1 Click Manual Add.
Figure 5-3
Figure 5-4
296
Copyright © NSS Sp. z o.o.
Figure 5-5
