User's Manual
1) Click Add.
2) Configure parameters.
Parameter
Type
Scene Name
Master Camera
Slave Camera
Step 3 Click Apply.
The monitoring area is successfully added.
Figure 4-168
Table 4-52
Description
Fisheye + PTZ:
● 1 Fisheye + 1 PTZ
● 1 Fisheye + 2 PTZ
● 1 Fisheye + 3 PTZ
This parameter is user defined.
Select a fisheye camera as needed.
1. Click Select in Master Camera line.
2. Select a fisheye camera in the prompted dialog box.
3. Click Apply.
Select speed domes as needed.
1. Click Select in Master Camera line.
2. Select speed domes in the prompted dialog box.
3. Click Apply.
