User's Manual
Parameter
Channel
Type
Protocol
Address
Baud rate
Data Bit
Stop Bit
Parity
Step 3 Click Apply.

1.4.2 PTZ Control

PTZ control panel performs the operations such as directing camera in eight directions,
adjusting zoom, focus and iris settings, and quick positioning.
Basic PTZ Control Panel
Right-click on the live view screen and then select PTZ. The PTZ control panel is displayed.
● The gray button means system does not support current function.
● For some series products, the PTZ function is valid in one-window mode.
Parameter
Speed
Table 4-26
Description
In the Channel list, select the channel that you want to connect the PTZ
camera to.
● Local: Connect through RS-485 port.
● Remote: Connect through network by adding IP address of PTZ
camera to the Device.
In the Protocol list, select the protocol for the PTZ camera such as
PELCOD.
In the Address box, enter the address for PTZ camera. The default is 1.
The entered address must be the same with the address configured on
the PTZ camera; otherwise the system cannot control PTZ camera.
In the Baud rate list, select the baud rate for the PTZ camera. The
default is 9600.
The default value is 8.
The default value is 1.
The default is value NONE.
Figure 4-94
Table 4-27
Description
Controls the movement speed. The bigger the value is, the faster the
movement will be.
