Illegal Login - BCS Line User Manual

269
Step 2 Select Enable and configure parameters. See Table 4-92.
Parameter
Alarm-out Port
Post-Alarm
Show Message
Buzzer
Alarm Tone
Log
Send Email
Step 3 Click Apply to complete the settings.

1.14.6.2 Illegal Login

Step 1 Select Main Menu > SECURITY > Security Warning > Illegal Login.
The Illegal Login interface is displayed. See Figure 4-280.
Copyright © NSS Sp. z o.o.
Figure 4-279 Security Exception
Table 4-92 Security exception parameters
Description
The alarm device (such as lights, sirens, etc.) is connected to the
alarm output port. When an alarm occurs, the NVR device
transmits the alarm information to the alarm device.
When the alarm ends, the alarm extended for a period of time. The
time range is from 0 seconds to 300 seconds.
Check box to enable a pop-up message in your local host PC.
Select the check box to activate the buzzer when an alarm occurs.
Check the box and then select the corresponding audio file from
the dropdown list. System plays the audio file when the alarm
occurs.
See "4.17.1 File Management" to add audio file first.
Select the check box, the NVR device records the alarm
information in the log when an alarm occurs.
Select the check box. When an alarm occurs, the NVR device
sends an email to the set mailbox to notify the user.
You need to set the email first. For details, see "4.11.10 Email".
Security Event monitoring explanation. It indicates the type of
attacks that can trigger security exception.
● Unauthorized executable program trying to run
● Web URL brute-force attack
● Session connection overload
● Session ID brute-force attack
269
User's Manual
