BCS Line User Manual page 33

User's Manual
Parameter
DHCP
IP Address
Subnet Mask
Default Gateway
DNS DHCP
Preferred DNS
Alternate DNS
Test
Step 4 Click OK to go to NIC settings.
Device goes back to TCP/IP interface.
Step 5 Set network parameters. See Table 4-6.
Parameter
IP Version
Preferred DNS server
Alternate DNS server
MAC Address
DHCP
Description
Enable the DHCP function. The IP address, subnet mask and
default gateway are not available for configuration once DHCP is
enabled.
● If DHCP is effective, the obtained information will display in
the IP Address box, Subnet Mask box and Default
Gateway box. If not, all values show 0.0.0.0.
● If you want manually configure the IP information, disable the
DHCP function first.
● If PPPoE connection is successful, the IP address, subnet
mask, default gateway, and DHCP are not available for
configuration.
Enter the IP address and configure the corresponding subnet
mask and default gateway.
IP address and default gateway must be in the same network
segment.
Enable the DHCP function to get the DNS address from router.
In the Preferred DNS box, enter the IP address of DNS.
In the Alternate DNS box, enter the IP address of alternate
DNS.
Click Test to test if the entered IP address and gateway are
interworking.
Table 4-6
Description
There are two options: IPv4 and IPv6. Right now, system
supports these two IP address format and you can access
via them.
DNS server IP address.
DNS server alternate address.
Displays the MAC address of the Device.
Enable the DHCP function. The IP address, subnet mask
and default gateway are not available for configuration once
DHCP is enabled.
● If DHCP is effective, the obtained information will display
in the IP Address box, Subnet Mask box and Default
Gateway box. If not, all values show 0.0.0.0.
● If you want manually configure the IP information,
disable the DHCP function first.
● If PPPoE connection is successful, the IP address,
subnet mask, default gateway, and DHCP are not
available for configuration.
22
