BCS Line User Manual

Network video recorder

page of 329

/ 329
Contents
Table of Contents
Bookmarks

Table of Contents

Quick Links

Download this manual

N E T WO RK V ID E O R ECOR D ER

User's Manual

www.bcs.pl

NSS Sp. z o.o. ul. Modularna 11 (Hala IV), 02-238 Warszawa

tel. +48 22 846 25 31, fax. +48 22 846 23 31 wew.140

e-mail: info@bcscctv.pl, NIP: 521-312-46-74

BCS LINE

V4.5.1

Table of Contents

Summary of Contents for BCS Line

Page 1 BCS LINE N E T WO RK V ID E O R ECOR D ER User‘s Manual www.bcs.pl NSS Sp. z o.o. ul. Modularna 11 (Hala IV), 02-238 Warszawa tel. +48 22 846 25 31, fax. +48 22 846 23 31 wew.140 e-mail: info@bcscctv.pl, NIP: 521-312-46-74...
Page 2 Safety Instructions The following categorized signal words with defined meaning might appear in the manual. Signal Words Meaning Indicates a potential risk which, if not avoided, could result in property damage, data loss, lower performance, or unpredictable result. Electrostatic Sensitive Devices. Indicates a device that is sensitive to electrostatic discharge.
Page 3: Important Safeguards And Warnings
Important Safeguards and Warnings The following description is the correct application method of the device. Read the manual carefully before use to prevent danger and property loss. Strictly conform to the manual during application and keep it properly after reading. Operating Requirement ●...
Page 4: Table Of Contents
Table of Contents Important Safeguards and Warnings ..................... II 1 Local Basic Operation .......................... 1 1.1 Getting Started ..........................1 1.1.1 Booting up ..........................1 1.1.2 Device Initialization ......................2 1.1.3 Resetting Password ......................5 1.1.3.1 Enabling Password Reset Function ................6 1.1.3.2 Resetting Password on Local Interface ..............
Page 5 1.2.6.1 Encode ......................... 54 1.2.6.2 Snapshot ........................56 1.2.7 Channel Name ........................57 1.2.8 Checking PoE Status ......................58 1.2.9 Remote Update ........................58 1.2.10 Remote Device Info ......................59 1.2.10.1 Device Status ......................59 1.2.10.2 Firmware ........................60 1.3 Live View ............................61 1.3.1 Live View ..........................
Page 6 1.4.4.1 Calling Presets ......................91 1.4.4.2 Calling Tours ....................... 91 1.4.4.3 Calling Patterns ......................91 1.4.4.4 Calling AutoScan ......................91 1.4.4.5 Calling AutoPan ......................91 1.4.4.6 Using Auxiliary Button ....................92 1.5 Record File ........................... 92 1.6 Playback and Search ........................92 1.6.1 Instant Playback ........................
Page 7 1.7.1.9.1 General ......................119 1.7.1.9.2 Fisheye ......................120 1.7.1.10 SMD .......................... 121 1.7.1.11 Analytics List ......................121 1.7.2 Parameters ........................122 1.7.2.1 Smart Plan ......................... 122 1.7.2.2 Face Detection ......................124 1.7.2.3 Face Recognition ...................... 127 1.7.2.3.1 Configuring AI by Recorder ................127 1.7.2.3.2 Configuring AI by Camera ................
Page 8 1.7.3.3.3 Import/Export Black/whitelist ................173 1.8 Event Manager ........................... 174 1.8.1 Alarm Info .......................... 174 1.8.2 Alarm Status ........................174 1.8.3 Alarm Input ........................175 1.8.4 Alarm Control ........................177 1.8.5 Video Detection ......................... 178 1.8.5.1 Motion Detection ...................... 178 1.8.5.1.1 Setting the Motion Detection Region .............
Page 9 1.10.4.4.1 Upgrading File ....................211 1.10.4.4.1 Upgrading File ....................211 1.10.4.4.2 Online Upgrade ....................212 1.10.4.4.2 Online Upgrade ....................212 1.10.4.4.3 Uboot Upgrading .................... 214 1.11 Network ............................ 214 1.10.4.4.3 Uboot Upgrading .................... 214 1.11 Network ............................ 214 1.11.1 TCP/IP ..........................214 1.11.1 TCP/IP ..........................
Page 10 1.12.9 Record Estimate ......................249 1.12.9.1 Calculating Recording Time .................. 250 1.12.9.2 Calculating HDD Capacity for Storage ..............251 1.12.10 FTP ..........................251 1.12.11 Setting iSCSI ......................... 253 1.13 System ............................254 1.13.1 General ..........................254 1.13.2 RS232 ..........................255 1.14 Security ............................
Page 11 User‘s Manual 1.17.3 Broadcast ........................286 1.18 USB Device Auto Pop-up ....................... 287 1.19 Shutdown ..........................288 2 Web Operation ........................... 292 2.1 Network Connection ......................... 292 2.2 Web Login ..........................292 2.3 Web Main Menu ......................... 293 2.4 Cluster Service .......................... 295 2.4.1 Cluster IP ...........................
Page 12: Local Basic Operation
User‘s Manual 1 Local Basic Operation Slight difference may be found on the user interface. The following figures are for reference only. 1.1 Getting Started This chapter introduces device initial settings such as boot up, device initialization, reset password, and quick settings. 1.1.1 Booting up ●...
Page 13: Device Initialization
User‘s Manual The device will verify license during booting up. If the verification failed, the following icon will be shown on the screen, contact the after-sale service for further information. This function is available on select models. Figure 4-1 1.1.2 Device Initialization If it is your first time to use the device, set a login password of admin (system default user).
Page 14 User‘s Manual Figure 4-2 Step 2 Set system time zone according to the actual environment. Refer to Table 4-4 for detailed information. Click to shut down the device. It is suitable for the system integrator or the user to shut down directly after setting the time zone. Step 3 Click Next.
Page 15 User‘s Manual Parameter Description In the Prompt Question box, enter the information that can remind you of the password. Prompt Question On the login interface, click , the prompt will display to help you reset the password. For your device own safety, create a strong password of your own choosing. We also recommend you change your password periodically especially in the high security system.
Page 16: Resetting Password
User‘s Manual ● The pattern that you want to set must cross at least four grids. ● If you do not want to configure the unlock pattern, click Skip. ● Once you have configured the unlock pattern, the system will require the unlock pattern as the default login method.
Page 17: Enabling Password Reset Function
User‘s Manual ● If the password reset function is enabled, you can use mobile phone to scan the QR code to reset the password. For details, see "4.1.3.2 Resetting Password on Local Interface". ● If the password reset function is disabled, there are two situations: If you configured security questions, you can reset the password by the security ◇...
Page 18: Resetting Password On Local Interface
User‘s Manual security questions). 1.1.3.2 Resetting Password on Local Interface Step 1 Enter the Login interface. ● If you have configured unlock pattern, the unlock pattern login interface is displayed. See Figure 4-7. Click Forgot Pattern, the password login interface is displayed.
Page 19 User‘s Manual To login from other user account, on the unlock pattern login interface, click Switch User, or on the password login interface, in the Switch User list, select other user to login. Figure 4-7 Copyright © NSS Sp. z o.o.
Page 20 User‘s Manual Figure 4-8 Step 2 Click ● If you have set the reserved email address, the Prompt interface is displayed. See Figure 4-9. Click OK. ● If you did not set the reserved email address, the email entering interface is displayed.
Page 21 User‘s Manual Figure 4-9 Figure 4-10 Step 3 Click Next. After clicking Next, the system will collect your information for password reset, purpose and the information includes but not limited to email address, MAC address, and device serial number. Read the prompt carefully before clicking Next. Step 4 Select a reset mode to reset the password.
Page 22 User‘s Manual Figure 4-11 Follow the on-screen instruction to acquire the security code from email. ◇ Enter security code and click Next. ◇ ● Security question On the Password Reset interface as shown below, in the Reset Mode list, select Security Question, the Security Questions interface is displayed.
Page 23 User‘s Manual If you did not configure the security questions before, in the Reset Type list, there is no Security Question. Figure 4-12 Step 5 Click Next. The Reset Password interface is displayed. See Figure 4-13. Figure 4-13 Step 6 In the New Password box, enter the new password and enter it again in the Confirm Password box.
Page 24: Reset Button
User‘s Manual A pop-up message is displayed asking if you want to sync the password with the remote devices. See Figure 4-14. Click OK to synchronize password to remote devices. Figure 4-14 1.1.3.3 Reset Button You can always use the reset button on the mainboard to reset the Device to the factory default settings.
Page 25: Quick Settings
User‘s Manual 1.1.4 Quick Settings After you successfully initialized the device, it goes to startup wizard. Here you can quickly configure your device. Click Next, device goes to General interface. The startup wizard interface only displays after you first login the device and have set the admin password.
Page 26 User‘s Manual Figure 4-17 Basic settings Step 2 Set parameters. See Table 4-3. Table 4-3 Basic parameters Parameter Description Device Name In the Device Name box, enter the Device name. Device No. In the Device No. box, enter a number for the Device. Language In the Language list, select a language for the Device system.
Page 27: Date And Time
User‘s Manual Parameter Description Adjust the speed of double-click by moving the slider. Mouse Sensitivity The bigger the value is, the faster the speed is. Step 3 Click Apply button to save settings. 1.1.4.1.2 Date and Time You can set device time. You can enable NTP (Network Time Protocol) function so that the device can sync time with the NTP server.
Page 28: Holiday
User‘s Manual Parameter Description Date Separator In the Date Separator list, select a separator style for the date. In the Time Format list, select 12-HOUR or 24-HOUR for the Time Format time display style. Enable the Daylight Saving Time function. Click Week or click Date.
Page 29 User‘s Manual Figure 4-19 Step 2 Click Add Holidays, the Add Holidays interface is displayed. See Figure 4-20. Figure 4-20 Step 3 Set holiday name, repeat mode and holiday mode. Click Add more to add new holiday information. Step 4 Click Add , you can add current holiday to the list.
Page 30: Basic Networking Settings
User‘s Manual 1.1.4.2 Basic Networking Settings You can set device IP address, DNS (Domain Name System) information. You can also configure basic network settings by selecting Main Menu > NETWORK > TCP/IP. Make sure the device has properly connected to the network. Step 1 Click Next.
Page 32 User‘s Manual Table 4-5 Parameter Description ● Multi-address: Two Ethernet ports work separately through either of which you can request the Device to provide the services such as HTTP and RTSP. You need to configure a default Ethernet port (usually the Ethernet port 1 by default) to request the services from the device end such as DHCP, Email and FTP.
Page 33 User‘s Manual Parameter Description Enable the DHCP function. The IP address, subnet mask and default gateway are not available for configuration once DHCP is enabled. ● If DHCP is effective, the obtained information will display in the IP Address box, Subnet Mask box and Default DHCP Gateway box.
Page 34: P2P
User‘s Manual 1.1.4.3 P2P Scan the QR code on the actual interface to download the cell phone app. Register an account and then you can use the smart phone to add the device. Before using the P2P function, make sure that the NVR has connected to the WAN. 1.1.4.3.1 Local Operation Step 1 Click Next button.
Page 35 User‘s Manual 1) Tap Device Manager. The Device Manager interface is displayed. See Figure 4-24. Figure 4-24 Device manager 2) Tap on the top right corner. The interface requiring device initialization is displayed. A pop-up message reminding you to make sure the Device is initialized is displayed. 3) Tap OK.
Page 36 User‘s Manual You can add wireless device or wired device. The Manual takes adding wired device as an example. Figure 4-25 5) Tap P2P. The P2P interface is displayed. See Figure 4-26. Figure 4-26 6) Enter a name for the NVR, the username and password, scan the QR code under Copyright ©...
Page 37: Adding Camera
User‘s Manual Device SN. 7) Tap Start Live Preview. The Device is added and displayed on the live view interface of the cell phone. See Figure 4-27. Figure 4-27 1.1.4.4 Adding Camera If you do not select Smart add function during the initialization process, go to the remote Device interface to register a remote device.
Page 38 User‘s Manual There are two ways to go to Registration interface. ● Select Main Menu > CAMERA > Camera List > Camera List, you can go to the Camera List interface. ● On the live view interface, right click mouse and then select Add Camera. Figure 4-28 Step 2 Register remote device.
Page 39 IP address. Click Search, the searched devices display in the searched device list. To adjust the display sequence, in the title line, you can click the IP address, Manufacturer, Type, MAC Address, Port, or Device Search Name text.
Page 40 User‘s Manual Figure 4-30 2. Configure parameters. See Table 4-8. Table 4-8 Parameter Description In the Channel list, select the channel that you want use on the Channel Device to connect the remote device. In the Manufacturer list, select the manufacturer of the remote Manufacturer device.
Page 41: Raid Manager
User‘s Manual Parameter Description If the remote device is added through Onvif protocol, selecting the Encrypt check box will provide encryption protection to the data being transmitted. Encrypt To use this function, the HTTPS function should be enabled for the remote IP camera. 3.
Page 42: Schedule
User‘s Manual Figure 4-32 Step 3 You can click Create RAID or Create Manually, and all the disks involved will be formatted. ● Click Create RAID, the system will create RAID automatically. If there is no existing RAID and no hot spare disk, the system will create RAID5 ◇...
Page 43: Recording Schedule
User‘s Manual 1.1.4.6.1 Recording Schedule After set schedule record, device can record video file according to the period you set here. For example, the alarm record period is from 6:00–18:00 Monday, device can record alarm video files during the 6:00–18:00. All channels are record continuously by default.
Page 44 User‘s Manual Parameter Description If there are several HDDs installed to the Device, you can set one of the HDDs as the redundant HDD to save the recorded files into different HDDs. In case one of the HDDs is damaged, you can find the backup in the other HDD.
Page 45 User‘s Manual Figure 4-34 Step 3 Set record type. See Figure 4-35. Figure 4-35 ● When the record type is Motion (motion detection), alarm, M&A, IVS and POS, enable the channel record function when corresponding alarm occurs. For example, when the alarm type is MD, select Main Menu > ALARM > Video Detection >...
Page 46 User‘s Manual If you have added a holiday, you can set the record period for the holiday. Figure 4-37 ● Define the period by drawing. 1. Select a corresponding date to set. Define for the whole week: Click next to All, all the icon switches to ◇...
Page 47 User‘s Manual Figure 4-38 The MD record and alarm record function are both null if you enabled MD&Alarm function. ● Define the period by editing. 1. Select a date and then click The Period interface is displayed. Figure 4-39 2. Set record type for each period. There are six periods for you to set for each day.
Page 48: Snapshot Schedule
User‘s Manual "4.1.4.6.3 Record Control" for detailed information. 1.1.4.6.2 Snapshot Schedule You can set schedule snapshot period. After set schedule snapshot, device can snapshot image according to the period you set here. For example, the alarm snapshot period is from 6:00–18:00 Monday, device can snapshot during the 6:00–18:00 when an alarm occurs.
Page 49: Record Control
User‘s Manual Figure 4-41 ● When the record type is Motion (motion detection), alarm, M&A, IVS and POS, enable the channel record function when corresponding alarm occurs. For example, when the alarm type is MD, select Main Menu > ALARM > Video Detection >...
Page 50 User‘s Manual You need to have storage authorities to implement the Manual record operation. Make sure the HDD has been properly installed. Step 1 Right click mouse and then select Manual Control > Record Mode or select Main Menu > STORAGE > Record. See Figure 4-43. Figure 4-43 Step 2 Configure parameters.
Page 51: Camera
User‘s Manual 1.2 Camera 1.2.1 Connection Select Main Menu > Camera > Camera List > Camera List, you can add remote devices. See Figure 4-44. After adding remote devices to the NVR, you can view the video on the NVR, and manage and storage the video file.
Page 52: Auto Changing H.265
User‘s Manual Check the box before several cameras, change the IP addresses of several cameras at the same time. Figure 4-45 Step 2 Select IP mode. ● Check DHCP, there is no need to input IP address, subnet mask, and default gateway.
Page 53: Ip Export
User‘s Manual Click H.265 Auto Switch at the bottom of the interface, it is from . The function is enabled. See Figure 4-44. Figure 4-46 1.2.1.3 IP Export Device can export the added device list to your local USB device. Step 1 Insert the USB device and then click the Export.
Page 54: Ip Import
User‘s Manual Figure 4-47 Step 2 Select Address to save export file. Step 3 Click OK. Step 4 Device pops up a dialogue box to remind you successfully exported. When exporting IP address, the Backup Encryption check box is checked by default. The file information includes IP address, port, channel number, manufacturer, user name, and password.
Page 55: Remote Device Initialization
User‘s Manual Figure 4-48 Step 2 Go to Address to select the import file and then click OK. System pops up a dialogue box to remind you successfully imported. If the imported IP has conflicted with current added device, system pops up a dialogue box to remind you.
Page 56 User‘s Manual Figure 4-49 Table 4-11 Parameter Description User The default is admin. Password The new password can be set from 8 characters through 32 characters and contains at least two types from number, letter and special characters (excluding"'", """, ";", ":" and "&"). Confirm Password Enter a strong password according to the password strength bar indication.
Page 57 User‘s Manual Figure 4-50 2) Configure parameters. Table 4-12 Parameter Description User The default is admin. Password The new password can be set from 8 characters through 32 characters and contains at least two types from number, letter and special characters (excluding"'", """, ";", ":" and "&"). Confirm Password Enter a strong password according to the password strength bar indication.
Page 58 User‘s Manual Figure 4-51 Step 6 Set email information. Input an email address for reset password purpose. Cancel the box and then click Next or Skip if you do not want to input email information here. Step 7 Click Next. The Network interface is displayed.
Page 59: Shortcut Menu To Add Camera
User‘s Manual ● Check DHCP, there is no need to input IP address, subnet mask, and default gateway. Device automatically allocates the IP address to the camera. ● Check Static, and then input IP address, subnet mask, default gateway and incremental value.
Page 60: Image
User‘s Manual Figure 4-54 Step 2 Click "+", device pops up interface to add network camera. Refer to "1.1.4.4 Adding Camera" for detailed information. 1.2.4 Image You can set network camera parameters according to different environments. It is to get the best video effect.
Page 61 User‘s Manual Figure 4-55 Step 2 Configure parameters. See Table 4-13. Different series network camera displays different parameters. The actual product shall prevail. Table 4-13 Parameter Description Channel In the Channel list, select the channel that you want to configure. There are three config files for you.
Page 62 User‘s Manual Parameter Description Adjusts the sharpness of image edge. The bigger the value is, the Sharpness more obvious the image edge is. Adjusts the sharpness according to actual environment. It is to adjust image brightness and enhance the image dynamic Gamma display range.
Page 63: Video Overlay
User‘s Manual Parameter Description You can set camera WB mode. It can affect the image whole hue so that the image can accurately display the environment status. WB Mode Different cameras supports different WB modes such as auto, manual ,natural light, outdoor and etc. Configure the color and black&white mode of the image.
Page 64: Privacy Masking
User‘s Manual 1.2.5.2 Privacy Masking You can set the privacy masking area on the screen to guarantee the privacy of the area. Step 1 Select Main Menu > CAMERA > Overlay > Privacy Masking. Figure 4-56 Step 2 Configure parameters. Table 4-15 Parameter Description...
Page 65: Encode
User‘s Manual 1.2.6.1 Encode You can set video bit stream parameters such as bit stream type, compression, resolution. Some series products support three streams: main stream, sub stream 1, sub stream 2. The sub stream maximally supports 1080p. Step 1 Select Main Menu >...
Page 66 User‘s Manual Parameter Description In the Compression list, select the encode mode. ● H.265: Main profile encoding. This setting is recommended. ● H.264H: High profile encoding. Low bit stream with high Compression definition. ● H.264: Main profile encoding. ● H.264B: Baseline profile encoding. This setting requires higher bit stream compared with other settings for the same definition.
Page 67: Snapshot
User‘s Manual Table 4-17 Parameter Description This function is enabled by default for main stream. You need to Audio manually enable it for sub stream 1. Once this function is enabled, the recorded video file is composite audio and video stream. Compression In the Compressiont list, select a format: G711a, G711u, PCM, AAC.
Page 68: Channel Name
User‘s Manual Parameter Description In the Type list, you can select Scheduled, or Event. ● Scheduled: The snapshot is taken during the scheduled period. Type ● Event: The snapshot is taken when there is an alarm event occurs, such as motion detection event, video loss, and local alarms.
Page 69: Checking Poe Status
User‘s Manual 1.2.8 Checking PoE Status You can check PoE ports status and set enhancement mode for each individual PoE port. Step 1 Select Main Menu > Camera > Camera List > PoE. Figure 4-61 Step 2 (Optional) Set Enhancement Mode to On or Off. When On is selected, the transmission distance of PoE port will be extended.
Page 70: Remote Device Info
User‘s Manual Figure 4-62 Step 2 Update the firmware of the connected remote device. ● Online Upgrade 1. Select a remote device and then click Manual Check. System detects the new version on the cloud. 2. Select a remote device that has new version and then click Online Update. After successful operation, system prompts update successful dialogue box.
Page 71: Firmware
User‘s Manual Figure 4-63 Table 4-19 Icon Description Icon Description IPC works properly. IPC does not support. There is an alarm. Video loss occurs. 1.2.10.2 Firmware You can view IP address, manufacturer, type, system version of the connected remote device. Select Main Menu >...
Page 72: Live View
User‘s Manual Figure 4-64 1.3 Live View After you logged in, the system goes to multiple-channel live view mode by default. You can view the monitor video of each channel. The displayed window amount may vary. The actual product shall prevail. 1.3.1 Live View On the live view interface, you can view the monitor video of each channel.
Page 73: Navigation Bar
User‘s Manual 1.3.2 Navigation bar You can quickly perform operation through the icon on the navigation bar. ● Different series products may display different navigation bar icons. Refer to the actual product for detailed information. ● Select Main Menu > SYSTEM > General > Basic to enable navigation bar function and then click Apply;...
Page 74: Channel Info
User‘s Manual Icon Function Open the Disk Manager interface. For details, see "4.12.3 Disk Manager". Open the USB Management interface. For details about USB operations, see "4.3.2.2 USB Management". 1.3.2.1 Channel Info After the remote device registered to the corresponding channel, you can view its status such as alarm status, record status, connection status, record mode, etc.
Page 75: Live View Control Interface
User‘s Manual Figure 4-67 1.3.3 Live View Control Interface Move your mouse to the top center of the video of current channel; you can see system pops up the live view control interface. See Figure 4-68. If your mouse stays in this area for more than 6 seconds and has no operation, the control bar automatically hides.
Page 76: Instant Replay
User‘s Manual ● Disable the navigation bar if it is displayed on the interface before using this function. ● The live view control interface is different depending on the model, and the actual interface shall prevail. Figure 4-68 1.3.3.1 Instant Replay You can play back the previous 5-60 minutes record of current channel.
Page 77 User‘s Manual Figure 4-69 Instant replay is to playback the previous 5 minutes to 60 minutes record of current channel. ● Move the slider to choose the time you want to start playing. ● Play, pause and close playback. ● The information such as channel name and recording status icon are shielded during instant playback and will not display until exited.
Page 78: Digital Zoom
User‘s Manual Figure 4-70 1.3.3.2 Digital Zoom You can zoom in specified zone of current channel so that you can view the details. It supports zoom in function of multiple-channel. It includes the following two ways: ● Click , the icon switches to .
Page 79: Instant Backup
User‘s Manual Figure 4-71 1.3.3.3 Instant Backup You can record the video of any channel and save the clip into a USB storage device. By clicking , the recording is started. To stop recording, click this icon again. The clip is automatically saved into the connected USB storage device.
Page 80: Shortcut Menu
User‘s Manual 1.3.3.7 Shortcut Menu By right-clicking on the live view interface, you can quickly access the corresponding functional interface and perform relevant operations, including entering the main menu, searching records and selecting screen split mode. Right-click on the live interface and the shortcut menu is displayed. Refer to Table 4-22 for detailed information.
Page 81 User‘s Manual ● If there are more than 30 faces, human bodies, and vehicles in the selected range, a prompt is displayed indicating that there are too many targets and the searching range should be reduced. The image stays frozen and you can start modifying range.
Page 82: Wireless Paring
User‘s Manual Playback". ● Lock recorded video: If you want to keep the recorded video permanently, select the picture, and then click Lock to lock video so that it cannot be overwritten and deleted. ● Back up recorded video or picture: Select the picture, and then click Backup. The Backup interface is displayed.
Page 83 User‘s Manual ● Enter edit view interface, device automatically switches to the max split amount mode. ● The channel list on the edit view interface displays the added camera channel number and channel name. means camera is online. means camera is offline.
Page 84: Fisheye (Optional)
User‘s Manual Figure 4-76 Step 3 Click Apply to save current channel sequence. After you change the channel sequence, click Cancel or right-click the live view interface, device pops up the dialogue box. See Figure 4-77. ● Click OK to save current settings. ●...
Page 85: Fisheye De-Warp During Preview Interface
User‘s Manual 1.3.6.1 Fisheye de-warp during preview interface The fisheye camera (panoramic camera) has wide video of angle but its video is seriously distorted. The de-warp function can present the proper and vivid video suitable for human eyes. On the preview interface, select fisheye channel and then right click mouse, you can select fish eye.
Page 86 User‘s Manual Figure 4-79 Refer to the following sheet for detailed information. See Table 4-23. Table 4-23 Installation modes Icon Note 360°panorama original view 1 de-warp window+1 panorama stretching 2 panorama stretching view (Wall mount) 1 360° panorama view+3 de-warp windows (Ground mount) 1 360°panorama view+4 de-warp windows 4 de-warp windows+1 panorama stretching...
Page 87: Fish Eye De-Warp During Playback
User‘s Manual Figure 4-80 In Figure 4-80, you can adjust the color pane on the left pane or use your mouse to change the position of the small images on the right pane to realize fish eye de-warp. Operation: Use mouse to zoom in/zoom out, move, and rotate the image (Not for wall mount mode.) 1.3.6.2 Fish eye de-warp during playback When playing back the fisheye record file, you can use de-warp function to adjust video.
Page 88: Ai Live View Mode
User‘s Manual Figure 4-81 1.3.8 AI Live View Mode When you select AI mode, the system displays information of human face, personnel, vehicle and non-motor vehicle on the right side of the preview interface, and it supports to play back records and display feature attributes.
Page 89 User‘s Manual Figure 4-82 Step 2 (Optional) Double-click the image on the right to play the corresponding video. Step 3 Click The Properties interface is displayed. See Figure 4-83. Figure 4-83 Step 4 (Optional) Click Show Face List and select attributes to display, including age, gender, expression, glasses, beard and mask.
Page 90 User‘s Manual Figure 4-84 Step 6 (Optional) Click Vehicle Display and select attributes to display, including vehicle logo, vehicle color, vehicle model, plate recognition, plate color, seatbelt, call, vehicle decorations and countries & regions. See Figure 4-85. Figure 4-85 Step 7 (Optional) Click Non-Motor and select attributes to display, including color, type and people number.
Page 91: Split Tracking
User‘s Manual Figure 4-86 Step 8 Click OK to complete the setting. The system can display four attributes at most. 1.3.9 Split Tracking You can track window split for a certain channel. This function is for select models only. Step 1 Right-click on the live view screen, and select Split Track.
Page 92 User‘s Manual Figure 4-87 Step 2 Select a split mode. Figure 4-88 Split mode includes full screen, 1 main screen + 3 split screens and 1 main screen + 5 split screens. ● You can move the rectangles with color to adjust the videos displayed on split screens.
Page 93: Quick Operation Bar
User‘s Manual Figure 4-89 1.3.10 Quick Operation Bar You can quickly access to the function modules on function tiles and setting menu through shortcut icons on quick operation bar. This topic uses ALARM and CAMERA as examples to show you how to quickly access other modules.
Page 94 User‘s Manual Figure 4-90 Table 4-24 Icon Description Click to jump to SEARCH interface. Click to jump to ALARM interface. Click to jump to AI interface. Click to jump to POS interface. Click to jump to NETWORK interface. Click to jump to MAINTAIN interface. Click to jump to BACKUP interface.
Page 95: Ptz
User‘s Manual Figure 4-91 Table 4-25 Icon Description Click to jump to CAMERA interface. Click to jump to NETWORK interface. Click to jump to STORAGE interface. Click to jump to SYSTEM interface. Click to jump to SECURITY interface. Click to jump to ACCOUNT interface. 1.4 PTZ PTZ is a mechanical platform that carries a camera and a protective cover and performs overall control remotely.
Page 96 User‘s Manual ● Local: The PTZ device connects to the NVR via the cable. ● Remote: The PTZ device connects to the NVR via the network. This function is for some series products only. Step 1 Select Main menu > Camera > PTZ. The PTZ interface is displayed.
Page 97: Ptz Control
User‘s Manual Table 4-26 Parameter Description In the Channel list, select the channel that you want to connect the PTZ Channel camera to. ● Local: Connect through RS-485 port. Type ● Remote: Connect through network by adding IP address of PTZ camera to the Device.
Page 98 User‘s Manual Parameter Description : Zoom out. Zoom : Zoom in. : Focus far. Focus : Focus near. : Image darker. Iris : Image brighter. PTZ movement Supports eight directions. Fast positioning button. ● Positioning: Click to enter the fast positioning screen, and then click anywhere on the live view screen, the PTZ will turn to this point and move it to the middle of the screen.
Page 99: Configuring Ptz Functions
User‘s Manual Icon Function Icon Function Click the AUX Config icon to open Scan the PTZ functions settings interface. Click the Enter Menu icon to open AUX Switch the PTZ Menu interface. 1.4.3 Configuring PTZ Functions 1.4.3.1 Configuring Presets Step 1 On the expanded PTZ control panel, click The Preset interface is displayed.
Page 100: Configuring Patterns
User‘s Manual Figure 4-97 Step 3 In the Tour No. box, enter the value for the tour route. Step 4 In the Preset box, enter the preset value. Step 5 Click Add Preset. A preset will be added for this tour. ●...
Page 101: Configuring Autoscan
User‘s Manual Figure 4-98 Step 3 In the Pattern box, enter the value for pattern. Step 4 Click Start to perform the directions operations. You can also go to the PTZ Control Panel to perform the operations of adjusting zoom, focus, iris, and directions. Step 5 On the PTZ interface, click End to complete the settings.
Page 102: Calling Ptz Functions
User‘s Manual 1.4.4 Calling PTZ Functions After you have configured the PTZ settings, you can call the PTZ functions for monitoring from the Expanded PTZ Control Panel. See Figure 4-100. Figure 4-100 1.4.4.1 Calling Presets Step 1 On the expanded PTZ control panel, in the No. box, enter the value of the preset that you want to call.
Page 103: Using Auxiliary Button
User‘s Manual 1.4.4.6 Using Auxiliary Button On the expanded PTZ control panel, click , the AUX setting interface is displayed. See Figure 4-100. In the Shortcut Aux list, select the option that corresponds to the applied protocol. In the Aux No. box, enter the number that corresponds to the AUX switch on the decoder. Figure 4-101 1.5 Record File Device adopts 24-hour continuous record by default.
Page 104 User‘s Manual The following figure is for reference only. Figure 4-102 Table 4-28 Function Description Display the searched recorded video or picture. It supports playing in single-channel, 4-channel, 9-channel, and 16-channel simultaneously. When playing back in a single channel mode, hold down Display Window the left mouse button to select the area that you want to enlarge.
Page 105 ● You can drag the vertical orange line on the time bar to rapidly view the playback in iframe format. ● When playing back video in one channel mode, you can move mouse pointer to time bar for 0.1 seconds...
Page 106: Playback Control
User‘s Manual Function Description ● In the Camera Name list, select the channel(s) that you want to play back. ● The window split is decided by how you select the channel(s). For example, if you select one channel, View Layout and the playback is displayed in the single-channel view;...
Page 107: Search Type
User‘s Manual Icon Function Backward play In normal play mode, left click the button, the file begins backward play. Click it again to pause current play. In backward play mode, click to restore normal play. Display previous frame/next frame. When pause the normal playback file, click to playback frame by frame.
Page 108: Clip
User‘s Manual Figure 4-104 ● From I/O Device: Recorded videos playback from external storage device. See Figure 4-105. Click Browse, select the save path of recorded video file that you want to play. Double-click the video file or click to start playing. Figure 4-105 1.6.2.3 Clip This function allows you to clip some footages to a new file and then save it to the USB device.
Page 109: Smart Search Playback
User‘s Manual Figure 4-107 Step 3 Click Backup to begin the process. 1.6.3 Smart Search Playback This function is for some series product only. During playback process, it can analyze the motion detect zone in the scene and give the analysis result.
Page 110: Picture Search Playback
User‘s Manual ● The motion detect region cannot be the full screen zone. ● The motion detect region adopts the current whole play pane by default. ● Selects the other file on the list, system begins playing the motion detect footages of other file.
Page 111 User‘s Manual Figure 4-109 Play back Tag During 1-window playback mode, click in Figure 4-102, you can go to tag file list interface. Double-click one tag file, you can begin playback from the tag time. Play before tag time Here you can set to begin playback from previous N seconds of the tag time. Usually, system can play back previous N seconds record if there is such kind of record file.
Page 112: Playback Image
User‘s Manual Figure 4-110 Modify Double-click one tag information item, you can see system pops up a dialogue box for you to change tag information. You can only change tag name here. Delete Here you can check the tag information item you want to delete and then click Delete, you can remove one tag item.
Page 113: File List
User‘s Manual This function is for some series products only. Step 1 Select Main Menu > SEARCH. The SEARCH interface is displayed. Step 2 In the Search Type list, select Subperiod; In the Split Mode list, select 4, 8, or 16. See Figure 4-111.
Page 114 User‘s Manual Figure 4-113 ● Check a file name, double-click the file or click to play. ● Input accurate time at the top column, you can search records of current day. ● System max displays 128 record files in one list. ●...
Page 115: Other Aux Functions
User‘s Manual Figure 4-114 1.6.9 Other Aux Functions 1.6.9.1 Digital Zoom In 1-window playback mode, left click mouse to select any zone on the screen, you can zoom in current zone. Right click mouse to exit. 1.6.9.2 Switch Channel ● During playback mode, select from the drop-down list to switch playback channel. ●...
Page 116: Face Detection
User‘s Manual This series NVR products support playback the AI by camera file only. AI by camera means the connected camera does all the AI analytics, and then gives the results to the NVR. 1.7.1.1 Face Detection You can search the detected faces and play back recordings. Step 1 Select Main Menu >...
Page 117 User‘s Manual For privacy reason, the human face in the image is pixelated. The actual image is clear. Figure 4-116 Step 3 Select the face that you want to play back. The picture with registered information is displayed. You can also do the following operations to the recorded files. ●...
Page 118: Face Recognition
User‘s Manual ● To lock the files to make it unable to be overwritten, select the files, and then click Lock. ● To add a tag to the file, select the files and then click Add Tag. ● Click Add to Face Database and enter corresponding information in the displayed interface, and then add the picture to the face database.
Page 119 User‘s Manual Figure 4-119 Step 2 Select the channel and set the parameters such as start time, end time, gender, age, glasses, beard, mask, and similarity according to your requirement. Step 3 Click Search. The search result is displayed. See Figure 4-120. Copyright ©...
Page 120: Search By Image
User‘s Manual The human face in the image is pixelated. The actual image is clear. Figure 4-120 Step 4 Click the picture that you want to play back. The picture with registered information is displayed. You can also do the following operations to the recorded files. ●...
Page 121 User‘s Manual Figure 4-121 Step 2 Select the channel and set the parameters such as start time, end time, gender, age, glasses, beard, mask, and similarity according to your requirement. Step 3 Click Search. The search result is displayed. See Figure 4-122. Copyright ©...
Page 122: Ivs
User‘s Manual The human face in the image is pixelated. The actual image is clear. Figure 4-122 Step 4 Click the picture that you want to play back. The picture with registered information is displayed. You can also do the following operations to the recorded files. ●...
Page 123: Stereo Analysis
User‘s Manual Figure 4-123 Step 2 Select a channel, start time, end time, event type, and then click Search. The search result is displayed. Step 3 Click the picture that you want to play back. You can also do the following operations to the recorded files. ●...
Page 124: Fall Detection
User‘s Manual Step 2 Select a channel and click Add. Step 3 Select Enable and set Type to People Approach Detection. Step 4 Click , and then click and hold left mouse key to draw an area on the screen. Step 5 Configure parameters.
Page 125: People Retention Detection
User‘s Manual Parameter Description Set the minimum time of triggering an alarm when the number of Duration people reaches threshold. Set repeat alarm time. If the alarm status continues, an alarm will Repeat Alarm Time be trigger again when repeat alarm time is reached. When the interval between people in the area is greater than or Alarm People No.
Page 126 User‘s Manual Figure 4-124 Step 2 Select a channel, start time, end time, and set corresponding parameters. Step 3 Click Search. The search result is displayed. See Figure 4-125. For privacy reason, the human face in the image is pixelated. Figure 4-125 Step 4 Select one or multiple results, and do the following operations as needed.
Page 127: Vehicle Detection
User‘s Manual ● Click Add to Face Database to add the picture to a face database. 1.7.1.6 Vehicle Detection You can search according to the vehicle parameters and search the alarm record during the specified period. This function is for some series products only. Step 1 Select Main Menu >...
Page 128: Non-Motor Vehicle Detection
User‘s Manual 3) To add a mark to the file, select the files and then click Add Tag. 1.7.1.7 Non-motor Vehicle Detection You can search according to the non-motor vehicle parameters and search the alarm record during the specified period. This function is for some series products only.
Page 129: People Counting
User‘s Manual Figure 4-128 Step 4 Select one or multiple results, and then you can do the following operations as needed. ● Click Export to export results in Excel format. ● To back up the recorded files to the external storage device, select files, click Backup, select the save path and file type, and then click Start.
Page 130: Heat Map
User‘s Manual Figure 4-129 Step 2 Set parameters such as channel, report type, start time, end time, etc. See Table 4-34. Table 4-34 Parameter Description Channel Select the channel you want to search people amount. Rule Select the rule from the drop-down list. Select report type from the drop-down list: daily report, monthly Report Type report, yearly report.
Page 131: Fisheye
User‘s Manual Figure 4-130 Step 2 Select channel, start time, end time. Step 3 Click Search. Step 4 System display heat map report. Click Export, and then select path. Click Save to save current report to the USB device. 1.7.1.9.2 Fisheye Step 1 Select Main Menu >...
Page 132: Smd
User‘s Manual Figure 4-131 Step 2 Set Channel, Type, Start Time, End time. Step 3 Click Search. Step 4 System displays heat map report. Click Export and then select saved path, click Save to save the heat map report to the USB device.
Page 133: Parameters
User‘s Manual Figure 4-132 Step 3 Click Search 1.7.2 Parameters 1.7.2.1 Smart Plan The smart plan is for the smart network camera. It includes IVS, human face detection, human face recognition, human body detection, people counting, heat map. If you do not set a rule here, you cannot use these AI intelligent functions when you are connecting to a smart network camera.
Page 134 User‘s Manual Figure 4-133 Step 2 Select a channel number. System displays different smart plan interfaces since the remote device may supports different functions. ● The interface is shown as Figure 4-134, if the remote device supports preset function. Figure 4-134 1.
Page 135: Face Detection
User‘s Manual 2. Select a preset. 3. Click the smart plan icon at the bottom left. The icon becomes highlighted. 4. Click Apply. Click to delete the preset. ◇ Click Add to add a preset. ◇ ● Once the remote device does not support preset function, the interface is shown as in Figure 4-135.
Page 136 User‘s Manual Figure 4-136 Step 2 In the Channel list, select a channel that you want to configure face detection function. Step 3 In the Type list, select AI by Reorder or AI by Camera as needed. When AI by Camera is selected, you can enable Face Enhancement function to improve face detection efficiency.
Page 137 User‘s Manual Parameter Description Select the check box. When an alarm occurs, the NVR device uploads an alarm signal to the network (including the alarm center). Report Alarm ● This function is for some series products only. ● You need to set the alarm center first. For details, see "4.11.13 Alarm Center".
Page 138: Face Recognition
User‘s Manual Parameter Description Click More to configure remote alarm output. When alarm event is triggered, the Device links the alarm output ports on camera to trigger an action, such as triggering an access controller to unlock door. ● Enable: Select the check box to enable the remote alarm output.
Page 139: Configuring Ai By Camera
User‘s Manual select the face database that you want to arm, and then click OK. Click to modify similarity, and click to configure alarm linkages. ● Stranger Alarm: The alarm is triggered when the similarity of detected faces does not reach the defined value. Select Stranger Alarm in AI Mode, click Setting next to Target Face Database, enable the function, and then set alarm linages.
Page 140: Ivs (General Behavior Analytics)
User‘s Manual Figure 4-139 AI by camera Step 3 Enable Face Enhancement. Then system displays human face at the enhanced way. Step 4 Click Rule to draw areas to filter the target. You can configure two filtering targets (maximum size and minimum size). When the target is smaller than the minimum size or larger than the maximum size, no alarms will be activated.
Page 141 User‘s Manual the backlight environment, avoid direct sunlight. Step 1 Select Main Menu > AI > Parameters > IVS. The IVS interface is displayed. See Figure 4-140. Figure 4-140 Step 2 Select a channel from the dropdown list. Click Add and then set corresponding rule. See Figure 4-141. Copyright ©...
Page 142: Tripwire
Set corresponding parameters. Step 4 Click Apply. 1.7.2.4.1 Tripwire When the detection target crosses the warning line along the set direction, the system performs an alarm linkage action. Step 1 Select Main Menu > AI > Parameters > IVS. In the Type drop-down list, select Tripwire. See Figure 4-142.
Page 143 User‘s Manual Figure 4-142 Step 2 Draw the detection rule. 1) Click to draw the rule on the surveillance video, the system displays as Figure 4-143. Figure 4-143 2) Configure the parameters. See Table 4-36. Copyright © NSS Sp. z o.o.
Page 144 When you select IVS of AI by camera, the connected channel shall support tripwire function. 3) Press and hold down the left button on the monitor screen to draw the line. The line can be a straight line or a curve.
Page 145 User‘s Manual Parameter Description Click Setting to draw areas to filter the target. You can configure two filtering targets (maximum size and minimum size). When the target is smaller than the minimum Rule size or larger than the maximum size, no alarms will be activated.
Page 146: Intrusion
User‘s Manual Parameter Description Select the check box and select the channel for tour. When an alarm occurs, the local interface of the NVR device displays the selected channel screen. Tour ● You need to set the time interval and mode for tour first, see "1.16.2 Tour".
Page 147: Abandoned Object Detection
User‘s Manual Figure 4-146 2) Configure the parameters. See Table 4-36. Table 4-38 Parameter Description Name Customize the rule name. Action Set the intrusion action, including appear and crossing area. Direction Set the direction to cross the area, including enter, exit and both. Click to filter the target.
Page 148 User‘s Manual Step 1 In the Type drop-down list, select Abandoned Object. The interface is shown as Figure 4-147. Figure 4-147 Step 2 Draw the detection rule. 1) Click to draw the rule on the surveillance video. See Figure 4-148. Copyright ©...
Page 149: Fast Moving
User‘s Manual Figure 4-148 2) Set parameters. See Table 4-39. Table 4-39 Parameter Description Preset Select a preset you want to use IVS. Name Input customized rule name System can generate an alarm once the object is in the zone for the Duration specified period.
Page 150 User‘s Manual Figure 4-149 Step 2 Draw the detection rule. 1) Click to draw the rule on the surveillance video. See Figure 4-150. Figure 4-150 2) Set parameters. See Table 4-40. Table 4-40 Parameter Description Preset Select a preset you want to use IVS Name Input customized rule name Copyright ©...
Page 151: Crowd Gathering
User‘s Manual Parameter Description You can set alarm sensitivity. The value ranges from 1 to 10.The Sensitivity default setup is 5. Click to filter the target. Check the blue wireframe and adjust the size of the area with the mouse. Each rule can set 2 target filters (maximum size and minimum Filter target size), that is, when the passing target is smaller than the minimum...
Page 152: Parking
User‘s Manual Figure 4-152 2) Set parameters. See Table 4-41. Table 4-41 Parameter Description Preset Select a preset you want to use IVS. Name Input customized rule name Duration Set the minimum time that the object stays until the alarm is triggered. Click to filter the target.
Page 153 User‘s Manual Figure 4-153 Step 2 Draw the detection rule. 1) Click to draw the rule on the surveillance video. See Figure 4-154. Figure 4-154 2) Set parameters. See Table 4-42. Table 4-42 Parameter Description Set the preset point for IVS detection according to the actual Preset needs.
Page 154: Missing Object Detection
User‘s Manual Parameter Description Name Customize the rule name. Set the minimum time that the object stays until the alarm is Duration triggered. Click to filter the target. Check the blue wireframe and adjust the size of the area with the mouse. Each rule can set 2 target filters (maximum size and minimum Filter target size), that is, when the passing target is smaller than the minimum...
Page 155: Loitering Detection
User‘s Manual Figure 4-156 2) Set parameters. See Table 4-43. Table 4-43 Parameter Description Set the preset point for IVS detection according to the actual Preset needs. Name Customize the rule name. Set the minimum time that the object stays until the alarm is Duration triggered.
Page 156 User‘s Manual Figure 4-157 Step 2 Draw the detection rule. 1) Click to draw the rule on the surveillance video. See Figure 4-158. Figure 4-158 2) Set parameters. See Table 4-44. Table 4-44 Parameter Description Preset Set the preset point for IVS detection according to the actual needs. Name Customize the rule name.
Page 157: Video Structuring (Metadata)
User‘s Manual Parameter Description Set the minimum time that the object stays until the alarm is Duration triggered. Click to filter the target. Check the blue wireframe and adjust the size of the area with the mouse. Each rule can set 2 target filters (maximum size and minimum Filter target size), that is, when the passing target is smaller than the minimum target or larger than the maximum target, no alarm will be...
Page 158: Crowd Distribution
User‘s Manual Parameter Description Select Motor Vehicle Detection and then check the box to Motor Vehicle Detection enable this function. Select Non-motor Vehicle Detection and then check the box to Non-motor Vehicle Detection enable this function. Step 3 Click Apply. 1.7.2.6 Crowd Distribution Connecting to the front-end device that supports crowd distribution function, system can support the crowd distribution function.
Page 159 User‘s Manual Parameter Description Configure the period and in the set time range, the corresponding Period configuration item will be linked to start the alarm. The alarm device (such as lights, sirens, etc.) is connected to the Alarm Out alarm output port. When an alarm occurs, the NVR device transmits the alarm information to the alarm device.
Page 160: People Counting
User‘s Manual Parameter Description Check the box and then select the corresponding audio file from the dropdown list. System plays the audio file when the alarm occurs. Voice Prompts Refer to "1.17.1 File Management" to add audio file first. Buzzer Select the check box to activate the buzzer when an alarm occurs.
Page 161 User‘s Manual Parameter Description Click to filter the target. Check the blue wireframe and adjust the size of the area with the mouse. Each rule can set 2 target filters (maximum size and minimum Filter target size), that is, when the passing target is smaller than the minimum target or larger than the maximum target, no alarm will be generated.
Page 162: Queuing
Select a region first to set the corresponding actions. For the same line, the queue people number alarm and queue time alarm has the same linkage actions. Step 1 Select Main Menu >...
Page 163 User‘s Manual Figure 4-162 Step 3 Select Channel, and then click Add. Step 4 Select the Enable check box. Step 5 Click to draw queuing rule and area. Step 6 Click under the Parameters column, and then select alarm type to Queue People No.
Page 164: Heat Map
User‘s Manual Parameter Description Select the check box and click Setting to select the channel and PTZ action. When an alarm occurs, the NVR device associates the channel to perform the corresponding PTZ action. For example, activate the PTZ in channel one to turn to the preset point X. PTZ Activation ●...
Page 165 User‘s Manual Figure 4-163 Step 2 Select a channel number and then check the box to enable the function. Step 3 Click Setting. The Setting interface is displayed. See Figure 4-164. Figure 4-164 Step 4 Set arm/disarm period. There are two modes for you to set the period so that the system can detect the specified zone.
Page 166: Anpr
User‘s Manual There are six periods for you to set for each day. ◇ Under Copy, select All to apply the settings to all the days of a week, or ◇ select specific day(s) that you want to apply the settings to. 2.
Page 167 User‘s Manual Table 4-50 Parameter Description Configure the period and in the set time range, the corresponding Period configuration item will be linked to start the alarm. The alarm device (such as lights, sirens, etc.) is connected to the Alarm Out alarm output port.
Page 168: Smd
User‘s Manual Parameter Description Check the box and then select the corresponding audio file from the dropdown list. System plays the audio file when the alarm occurs. Voice Prompts Refer to "1.17.1 File Management" to add audio file first. Buzzer Select the check box to activate the buzzer when an alarm occurs.
Page 169 User‘s Manual Parameter Description The alarm device (such as lights, sirens, etc.) is connected to the Alarm-out Port alarm output port. When an alarm occurs, the NVR device transmits the alarm information to the alarm device. When the alarm ends, the alarm extended for a period of time. Post-Alarm The time range is from 0 seconds to 300 seconds.
Page 170: Master-Slave Tracking
User‘s Manual Parameter Description Select the Snapshot check box to take a snapshot of the selected channel. Picture Storage To use this function, select Main Menu > CAMERA > Encode > Snapshot, select Event in Type list. Select the check box to activate the buzzer when an alarm Buzzer occurs.
Page 171 ● 1 Fisheye + 3 PTZ Scene Name This parameter is user defined. Select a fisheye camera as needed. 1. Click Select in Master Camera line. Master Camera 2. Select a fisheye camera in the prompted dialog box. 3. Click Apply.
Page 172 User‘s Manual Figure 4-169 Step 4 Configure calibration points to set the binding relationship of fisheye camera and speed dome. Set a distant place as the first calibration point to improve accuracy. 1) Click or double-click the target scene. 2) Click the target place on the video of fisheye camera, or move to the target place.
Page 173: Video Quality Analytics
User‘s Manual Table 4-53 Icon Description Zoom in/zoom out. Adjust resolution. Adjust height. Electronic mouse. You can use this icon to move the mouse to control PTZ direction. Quick positioning key. Click this icon to select a place, and the screen will be focused and centered on the selected place.
Page 174 User‘s Manual Figure 4-172 Step 3 Click Setting next to Rule. Step 4 Select items and set thresholds as needed . Figure 4-173 The value range of threshold is 0–100, ant the default value is 30. When the value exceeds the set threshold, an alarm will be triggered. Parameter Description Stripes refer to the striped interferences in the video which might be...
Page 175: Database
User‘s Manual Parameter Description An image in the video is generally a colorful image that contains Color Cast color information, such as RGB. When these three components appear at some unusual scale in an image, the image is biased. An image with high resolution contains more details, but image blur is a common problem of image quality decrease which is caused by Defocus many factors in the process of image acquisition, transmission and...
Page 176: Creating Face Database
User‘s Manual For privacy reason, the human face is pixelated. 1.7.3.1 Creating Face Database Step 1 Select Main Menu > AI > Database > Face Database Config. The Face Database Config interface is displayed. See Figure 4-174. Figure 4-174 Step 2 Select a channel and then click Add.
Page 177: Adding Face Pictures
User‘s Manual Figure 4-175 Step 3 Enter human face database name and then click OK. System successfully saves the face library. 1.7.3.1.1 Adding Face Pictures You can add face pictures to the existing libraries one by one or by batch, or add from the detected faces.
Page 178 User‘s Manual Figure 4-176 Step 3 Click Register. The Register interface is displayed. See Figure 4-177. Figure 4-177 Step 4 Click to add a face picture. The Browse interface is displayed. See Figure 4-178. Copyright © NSS Sp. z o.o.
Page 179 User‘s Manual Figure 4-178 Step 5 Select a face picture and enter the registration information. See Figure 4-179. Figure 4-179 Step 6 Click OK. The system prompts the registration is successful. Step 7 On the Details interface, click Search. The system prompts modeling is successful. See Figure 4-180. Copyright ©...
Page 180: Adding Face Pictures In Batches
User‘s Manual If the system prompts the message indicating modeling is in process, wait a while and then click Search again. If modeling is failed, the registered face picture cannot be used for face recognition. Figure 4-180 1.7.3.1.3 Adding Face Pictures in Batches System supports batch add if you want to import several human face image at the same time.
Page 181: Exporting/Importing Face Database
User‘s Manual Figure 4-181 Step 5 Click Select pictures, maximum 256 each time or Select a Folder to import face pictures. Step 6 Click OK to complete batch registration. 1.7.3.2 Exporting/Importing Face Database You can export and import local face database. 1.7.3.2.1 Exporting Face Database Step 1 Select Main Menu >...
Page 182: Importing Face Database
User‘s Manual ● Password is required; otherwise the imported database cannot be saved. ● The address switches to /NVR/Facelib/ automatically if this directory is not changed. Figure 4-182 Export Step 4 Click OK to start exporting face database, and you can view the progress on the exporting interface.
Page 183: Black/Whitelist
User‘s Manual ● Password is required and must be the same with password for export; otherwise the imported database cannot be saved. ● The address switches to /NVR/Facelib/ automatically if this directory is not changed. Step 4 Click OK to start importing face database, and you can view the progress on the importing interface.
Page 184: Deleting Black/White List
User‘s Manual The change of black list/white list configurations on NVR will be synchronized to ITC that supports black list/white list function. 1.7.3.3.2 Deleting Black/White List Set type as White List, Black List, or All, and then click Search. System displays black/whitelist information.
Page 185: Event Manager
User‘s Manual 1.8 Event Manager 1.8.1 Alarm Info You can search, view and back up the alarm information. Step 1 Select Main Menu > ALARM > Alarm Info. The Alarm Info interface is displayed. See Figure 4-186. Figure 4-186 Step 2 In the Type list, select the event type;...
Page 186: Alarm Input
User‘s Manual Figure 4-187 1.8.3 Alarm Input Step 1 Select Main menu > ALARM > Alarm-in Port. The Alarm-in Port interface is displayed. See Figure 4-188. Step 2 There are four alarm types. ● Local alarm: After connect the alarm device to the NVR alarm input port, system can trigger the corresponding alarm operations when there is alarm signal from the alarm input port to the NVR.
Page 187 User‘s Manual Figure 4-188 Step 3 Set Alarm-in Port channel number and then select the Enable check box to enable the function. Step 4 Configure parameters. See Table 4-56. Table 4-56 Parameter Description Alarm-in Port Select a channel to set alarm. Enable Check the box to enable the function.
Page 188: Alarm Control
User‘s Manual Parameter Description Select the check box. When an alarm occurs, the NVR device sends an email to the set mailbox to notify the user. Send Email You need to set the email first. For details, see "1.11.10 Email". Select the check box and select the needed recording channel (support multiple choices).
Page 189: Video Detection
User‘s Manual when an alarm occurs. ● Auto: Once an alarm event occurs, system can generate an alarm. ● Manual: Alarm device is always on the alarming mode. ● Off: Disable alarm output function. Step 1 Select Main menu > ALARM > Alarm-out Port. The Alarm-out Port interface is displayed.
Page 190 User‘s Manual Step 1 Select Main menu > ALARM > Video Detection > Motion Detection. The Motion Detection interface is displayed. See Figure 4-190. Figure 4-190 Step 2 Configure the settings for the motion detection parameters. See Table 4-57. Table 4-57 Parameter Description Channel...
Page 191 User‘s Manual Parameter Description Select the check box. When an alarm occurs, the NVR device uploads an alarm signal to the network (including the alarm center). Report Alarm ● This function is for some series products only. ● You need to set the alarm center first. For details, see "1.11.13 Alarm Center".
Page 192: Setting The Motion Detection Region
User‘s Manual ● Click Default to restore the default setting. ● Click Copy to, in the Copy to dialog box, select the additional channel(s) that you want to copy the motion detection settings to, and then click Apply. ● Click Test to test the settings. 1.8.5.1.1 Setting the Motion Detection Region Step 1 Next to Region, click Setting.
Page 193: Setting Schedule
User‘s Manual 1.8.5.1.2 Setting Schedule The system only activates the alarm in the defined period. Step 1 Next to Schedule, click Setting. The Setting interface is displayed. See Figure 4-192. Figure 4-192 Step 2 Define the motion detection period. By default, it is active all the time. ●...
Page 194: Video Tampering
User‘s Manual Figure 4-193 2. Enter the time frame for the period, and then select the check box to enable the settings. There are six periods for you to set for each day. ◇ Under Copy to, select All to apply the settings to all the days of a week, or ◇...
Page 195: Video Loss
User‘s Manual Figure 4-194 Step 2 To configure the settings for the tampering detection parameters, see "1.8.5.1 Motion Detection". The Tampering function does not have region and sensitivity items. Step 3 Click Apply to complete the settings. ● Click Default to restore the default setting. ●...
Page 196: Scene Change
User‘s Manual Figure 4-195 Step 2 To configure the settings for the video loss detection parameters, see "1.8.5.1 Motion Detection". The video loss function does not have region and sensitivity items. Step 3 Click Apply to complete the settings. ● Click Default to restore the default setting. ●...
Page 197: Pir Alarm
User‘s Manual Figure 4-196 Step 2 To configure the settings for the scene change parameters, see "1.8.5.1 Motion Detection". Step 3 The scene change function does not have region and sensitivity items. Step 4 Click Apply to complete the settings. ●...
Page 198: Audio Detection
User‘s Manual Figure 4-197 Step 2 To configure the settings for the PIR alarm parameters, see "1.8.5.1 Motion Detection". Step 3 Click Apply to complete the settings. ● Click Default to restore the default setting. ● Click Copy to, in the Copy to dialog box, select the additional channel(s) that you want to copy the motion detection settings to, and then click Apply.
Page 199 User‘s Manual Parameter Description The higher the value is, the easier it is to trigger an alarm. But at the Sensitivity same time, the false alarm may occur. The default value is recommended. You can set intensity change threshold. The smaller the value is, the Threshold higher the sensitivity is.
Page 200: Thermal Alarm
User‘s Manual Parameter Description Select the Snapshot check box to take a snapshot of the selected channel. Snapshot To use this function, select Main Menu > CAMERA > ENCODE > Snapshot, in the Mode list, select Event (Trigger). Select the check box, the NVR device records the alarm information in the log when an alarm occurs.
Page 201 User‘s Manual Figure 4-198 Step 2 Select a channel and alarm type, enable the thermal alarm function. Step 3 Select fire mode and then enable this function (If the alarm type is Fire Alarm). System supports preset mode and zone excluded mode. ●...
Page 202: Exception
User‘s Manual Parameter Description Select the check box and select the needed recording channel (support multiple choices). When an alarm occurs, the NVR device activates the channel for recording. Record Channel You need to enable intelligent recording and auto recording first. For details, see "1.1.4.6 Schedule".
Page 203 User‘s Manual The Exception interface is displayed. See Figure 4-199.Figure 4-199 Figure 4-200 Copyright © NSS Sp. z o.o.
Page 204 User‘s Manual Figure 4-201 Step 2 Configure parameters. See Table 4-61. Table 4-61 Parameter Description ● Disk: Sets process method when there is a HDD event such as HDD error, no HDD, no space. ● Network: Sets process method when there is a network event such as disconnection, IP conflict, MAC conflict.
Page 205: Disarming
User‘s Manual Parameter Description Select the check box and select the needed recording channel (support multiple choices). When an alarm occurs, the NVR device activates the channel for recording. Record Channel You need to enable intelligent recording and auto recording first. For details, see "1.1.4.6 Schedule".
Page 206: Pos
User‘s Manual Figure 4-202 Step 3 Select alarm linkage actions to disarm. All alarm linkage actions will be disarmed when you select All. Step 4 Click Apply. 1.9 POS You can connect the Device to the POS (Point of Sale) machine and receive the information from it.
Page 207: Settings
User‘s Manual Figure 4-203 Step 2 In the POS Search box, enter the information such as transaction number on your receipt, amount, or product name. Step 3 In the Start Time box and End Time box, enter the time period that you want to search the POS transaction information.
Page 208 User‘s Manual Figure 4-204 Step 2 Configure the settings for the POS parameters. See Table 4-62. Table 4-62 Parameter Description In the POS Name list, select the POS machine that you want to configures settings for. Click to modify the POS name. POS Name ●...
Page 209: Privacy Setup
There is no line delimiter by default. After set the line delimiter (HEX), the overlay information after the delimiter is displayed in the new line. For example, the line delimiter is F and the overlay information is 123156789, NVR displays overlay...
Page 210: Connection Type
User‘s Manual Figure 4-205 Step 2 Set privacy information. Step 3 Click OK. 1.9.2.2 Connection type Connection type is UDP or TCP. Step 1 Select Connection Mode as UDP, TCP_CLINET or TCP. Step 2 Click The IP Address interface is displayed. See Figure 4-206. Figure 4-206 Step 3 Enter Source IP and Port.
Page 211 User‘s Manual Figure 4-207 Step 2 In the Type list, select the log type that you want to view (System, Config, Storage, Record, Account, Clear Log, Playback, and Connection) or select All to view all logs. Step 3 In the Start Time box and End Time box, enter the time period to search, and then click Search.
Page 212: System
User‘s Manual Figure 4-208 ● Click Details or double-click the log that you want to view, the Detailed Information interface is displayed. Click Next or Previous to view more log information. ● Click Backup to back up the logs into the USB storage device. ●...
Page 213: Bps
User‘s Manual Figure 4-209 Table 4-63 Parameter Description Indicates the number of the currently connected HDD. The asterisk (*) means the current working HDD. Device Name Indicates name of HDD. Physical Position Indicates installation position of HDD. Properties Indicates HDD type. Total Space Indicates the total capacity of HDD.
Page 214: Device Status
User‘s Manual Figure 4-210 1.10.2.5 Device Status You can view fan running status such as speed, CPU temperature, and memory. Select Main Menu > MAINTAIN > System Info > Device Status, the Device Status interface is displayed. See Figure 4-211. Copyright ©...
Page 215: Network
User‘s Manual Figure 4-211 1.10.3 Network 1.10.3.1 Online User You can view the online user information or block any user for a period of time. To block an online user, click and then enter the time that you want to block this user. The maximum value you can set is 65535.
Page 216: Network Load
User‘s Manual Figure 4-212 1.10.3.2 Network Load Network load means the data flow which measures the transmission capability. You can view the information such as data receiving speed and sending speed. Step 1 Select Main Menu > MAINTAIN > Network > Network Load. The Network Load interface is displayed.
Page 217: Network Test
User‘s Manual Figure 4-213 Step 2 Click the LAN name that you want to view, for example, LAN1. The system displays the information of data sending speed and receiving speed. ● System displays LAN1 load by default. ● Only one LAN load can be displayed at one time. 1.10.3.3 Network Test You can test the network connection status between the Device and other devices.
Page 218: Maintenance And Management
User‘s Manual Figure 4-214 Step 2 In the Destination IP box, enter the IP address. Step 3 Click Test. After testing is completed, the test result is displayed. You can check the evaluation for average delay, packet loss, and network status. 1.10.4 Maintenance and Management 1.10.4.1 Device Maintenance When the Device has been running for a long time, you can configure the auto reboot when the...
Page 219: Exporting System Settings
User‘s Manual Figure 4-215 Step 2 Configure the settings for the system maintenance parameters. See Table 4-64. Table 4-64 Parameter Description Auto Reboot In the Auto Reboot list, select the reboot time. In the Case Fan Mode list, you can select Always run or Auto. If you select Auto, the case fan will stop or start according to the external conditions such as the Device temperature.
Page 220 User‘s Manual Figure 4-216 Step 2 Insert a USB storage device into one of the USB ports on the Device. Step 3 Click Refresh to refresh the interface. The connected USB storage device is displayed. See Figure 4-217. Copyright © NSS Sp. z o.o.
Page 221: Default
User‘s Manual Figure 4-217 Step 4 Click Export. There is a folder under the name style of "Config_[YYYYMMDDhhmmss]". Double-click this folder to view the backup files. 1.10.4.3 Default This function is for admin account only. You can select the settings that you want to restore to the factory default. Step 1 Select Main Menu >...
Page 222: System Update
User‘s Manual Figure 4-218 Step 2 Restore the settings. ● Click Default, and then click OK in the prompted dialog box. The system starts restoring the selected settings. ● Click Factory Default, and then click OK in the prompted dialog box. 1.
Page 223: Online Upgrade
User‘s Manual Figure 4-219 Step 3 Click Update. The Update interface is displayed. See Figure 4-220. Figure 4-220 Step 4 Click the file that you want to upgrade. Step 5 The selected file is displayed in the Update File box. Step 6 Click Start.
Page 224 User‘s Manual system. Before using this function, you need to check whether there is any new version by auto check or manual check. ● Auto check: The Device checks if there is any new version available at intervals. ● Manual check: Perform real-time check whether there is any new version available. Ensure the correct power supply and network connection during upgrading;...
Page 225: Uboot Upgrading
User‘s Manual 1.10.4.4.3 Uboot Upgrading ● Under the root directory in the USB storage device, there must be "u-boot.bin.img" file and "update.img" file saved, and the USB storage device must be in FAT32 format. ● Make sure the USB storage device is inserted; otherwise the upgrading cannot be performed.
Page 226 User‘s Manual Figure 4-222 Table 4-65 Parameter Description ● Multi-address: Two Ethernet ports work separately through either of which you can request the Device to provide the services such as HTTP and RTSP. You need to configure a default Ethernet port (usually the Ethernet port 1 by default) to request the services from the device end such as DHCP, Email and FTP.
Page 227: Port
User‘s Manual Parameter Description In the Ethernet Card list, select an Ethernet port as a default port. Default Ethernet This setting is available only when the Multi-address is selected in Port the Net Mode list. In the IP Version list, you can select IPv4 or IPv6. Both versions are IP Version supported for access.
Page 228 User‘s Manual Figure 4-223 Step 2 Configure the settings for the connection parameters. See Table 4-66. The connection parameters except Max Connection cannot take effects until the Device has been restarted. Table 4-66 Parameter Description The allowable maximum clients accessing the Device at the same time, such as WEB, Platform, and Mobile Phone.
Page 229: External Wi-Fi
User‘s Manual 1.11.3 External Wi-Fi The device can be connected via wireless network with an external Wi-Fi module, and it can reduce the difficulty of device connection without a network cable. Prerequisites Make sure that external Wi-Fi module is installed on the device. This function is supported on select models.
Page 230: Wi-Fi Ap
User‘s Manual Step 3 Click Apply. ● After the connection is successful, a Wi-Fi connection signal flag appears in the upper-right corner of the live view interface. ● The Wi-Fi module models currently supported are D-LINK, dongle and EW-7811UTC wireless cards. 1.11.4 Wi-Fi AP Prerequisites This function requires the built-in Wi-Fi module in the device, and actual product shall prevail.
Page 231: Advanced Settings
User‘s Manual Figure 4-225 Step 2 Select Wi-Fi to enable Wi-Fi. Step 3 Configure parameters. For details, see Table 4-68. Table 4-68 Parameter Description SSID Wi-Fi name for the device. Hide SSID You can hide the Wi-Fi name when select this option. Select an encryption mode.
Page 232 User‘s Manual Figure 4-226 Step 2 Configure parameters. For details, see Table 4-69. Table 4-69 Parameter Description IP Address Set IP address, subnet mask and default gateway for the Wi-Fi parameters of NVR. Subnet Mask IP address and default gateway must be in the same network Default Gateway segment.
Page 233 User‘s Manual This function is supported on select models. Procedure Step 1 Select Main Menu > NETWORK > 3G/4G Figure 4-227 The interface is divided into three main areas: ● Zone 1 displays a 3G/4G signal indication. ● Zone 2 displays 3G/4G module configuration information. ●...
Page 234: Repeater
Select Main Menu > NETWORK > REPEATER. The REPEATER interface is displayed. See Figure 4-228. ● Green connection line represents the successful connection between channel and wireless IPC. ● Auto cascade：After selecting auto cascade, the IPC can cascade to NVR automatically.
Page 235: Pppoe
User‘s Manual Manual cascade: You can use manual cascade when there are 2 IPCs in the network at least. Figure 4-229 Step 4 Click and select the channel to be added. The following interface is displayed after successful adding. See Figure 4-230. Figure 4-230 1.11.7 PPPoE PPPoE is another way for the Device to access the network.
Page 236: Ddns
User‘s Manual 1.11.7 PPPoE PPPoE is another way for the Device to access the network. You can establish network connection by configuring PPPoE settings to give the Device a dynamic IP address in the WAN. To use this function, firstly you need to obtain the user name and password from the Internet Service Provider.
Page 237: Upnp
User‘s Manual Figure 4-232 Step 2 Configure the settings for the DDNS parameters. See Table 4-71. Table 4-71 Parameter Description Enable the DDNS function. Enable After enabling DDNS function, the third-party might collect your Device information. Type Type and address of DDNS service provider. ●...
Page 238: Configuration Upnp
User‘s Manual Step 3 Connect the Device with the LAN port on the router to connect into the LAN. Step 4 Select Main Menu > NETWORK > TCP/IP, configure the IP address into the router IP address range, or enable the DHCP function to obtain an IP address automatically. 1.11.9.2 Configuration UPnP Step 1 Select Main Menu >...
Page 239: Email
User‘s Manual Parameter Description Indicates the status of UPnP function. Status ● Offline: Failed. ● Online: Succeeded. Enter IP address of router on the LAN. LAN IP After mapping succeeded, the system obtains IP address automatically without performing any configurations. Enter IP address of router on the WAN.
Page 240 User‘s Manual Figure 4-235 Step 2 Configure the settings for the email parameters. See Table 4-73. Table 4-73 Parameter Description Enable Enable the email function. Enter the address of SMTP server of sender’s email account. SMTP Server Enter the port value of SMTP server. The default value setting is 25. Port You can enter the value according to your actual situation.
Page 241: Snmp
User‘s Manual Parameter Description This is the interval that the system sends an email for the same type of alarm event, which means, the system does not send emails Interval (Sec.) caused by frequent alarm events. The value ranges from 0 to 3600. 0 means that there is no interval. Enable the health test function.
Page 242 User‘s Manual Figure 4-236 Step 2 Configure the settings for the SNMP parameters. See Table 4-74. Table 4-74 Parameter Description Enable Enable the SNMP function. Select the check box of SNMP version(s) that you are using. Version The default version is V3. There is a risk of select V1 or V2. SNMP Port Indicates the monitoring port on the agent program.
Page 243: Multicast
User‘s Manual Parameter Description In the Encryption Type list, select an encryption type. The default Encryption Type setting is CBC-DES. Step 3 Compile the two MIB files by MIB Builder. Step 4 Run MG-SOFT MIB Browser to load in the module from compilation. Step 5 On the MG-SOFT MIB Browser, enter the Device IP that you want to manage, and then select the version number to query.
Page 244: Alarm Center
User‘s Manual You can use the multicast IP address to login the web. On the web login dialog box, in the Type list, select MULTICAST. The web will automatically obtain the multicast IP address and join. Then you can view the video through multicast function.
Page 245: Register
User‘s Manual 1.11.14 Register You can register the Device into the specified proxy server which acts as the transit to make it easier for the client software to access the Device. Step 1 Select Main Menu > NETWORK > Register. The Register interface is displayed.
Page 246 User‘s Manual ● Only models with PoE ports support this function. ● Do not connect the PoE port with a switch, otherwise it will cause connection failure. ● This function is enabled by default, and the IP segment start from 10.1.1.1, we recommend that you use the default setting.
Page 247: P2P
User‘s Manual PoE Status Description PoE connection The PoE ports are bound to corresponding channels. When an IPC mapping is connected to PoE port 1, the corresponding channel is Channel 1. 1.11.16 P2P P2P is a kind of convenient private network penetration technology. You do not need to apply for dynamic domain name, doing port mapping or deploying transit server.
Page 248: Mobile App Operation
User‘s Manual manual. You can also enter the QR code of Cell Phone Client and Device SN by clicking on the top right of the interfaces after you have entered the Main Menu. 1.11.16.1 Mobile APP Operation The following contents are introduced in the example of mobile App. Step 1 Scan the QR code to download and install the mobile App.
Page 249: Basic
User‘s Manual 1.12.1 Basic You can set basic storage parameters. Step 1 Select Main Menu > STORAGE > BASIC. The Basic interface is displayed. See Figure 4-243. Figure 4-243 Step 2 Set parameters. See Table 4-79. Table 4-79 Parameter Description Configure the settings for the situation all the read/write discs are full, and there is no more free disc.
Page 250: Record Control
User‘s Manual Figure 4-244 Step 2 Select a HDD and then select a time from the drop-down list. Step 3 (Optional) Format a HDD. 1) Select a HDD and then click Format. 2) Click OK. 3) Enter the admin password and click OK. ●...
Page 251: Disk Quota
User‘s Manual Figure 4-245 Step 2 Select the group for each HDD group, and then click Apply to save the settings. After configuring HDD group, under the Main Stream tab, Sub Stream tab and Snapshot tab, configure settings to save the main stream, sub stream and snapshot to different HDD group as selected by you.
Page 252: Disk Check
User‘s Manual Figure 4-246 Step 2 Select a channel and set the values of record duration, bit rate and storage capacity of picture. Step 3 Click Apply. 1.12.7 Disk Check The HDD detect function is to detect HDD current status so that you can clearly understand the HDD performance and replace the malfunction HDD.
Page 253: Detect Report
User‘s Manual Figure 4-247 Step 2 In the Type list, select Key Area Detect or Global Check; and in the Disk list, select the HDD that you want to detect. Step 3 Click Start Check. The system starts detecting the HDD and displays the detection information. When system is detecting HDD, click Stop Check to stop current detection.
Page 254 User‘s Manual Figure 4-248 Step 2 Click The Details interface is displayed. You can view detecting results and S.M.A.R.T reports. See Figure 4-249 and Figure 4-250. Copyright © NSS Sp. z o.o.
Page 255: Disk Health Monitoring
User‘s Manual Figure 4-249 Figure 4-250 1.12.7.3 Disk Health Monitoring Monitor health status of disks, and repair if any exceptions are found so as to avoid data loss. Select Main Menu > STORAGE > Disk Check > Health Monitoring Click to show disk details interface.
Page 256: Raid
User‘s Manual Figure 4-251 Disk details 1.12.8 RAID RAID (redundant array of independent disks) is a data storage virtualization technology that combines multiple physical HDD components into a single logical unit for the purposes of data redundancy, performance improvement, or both. ●...
Page 257 User‘s Manual function, you can select the physical HDD that does not included in the RAID group or the created disk array to create a RAID5. You can refer to the following situations: ● There is no RAID, no hotspare disk: System directly creates the RAID5 and creates one hotspare disk at the same time.
Page 258: Raid Info
User‘s Manual 2. Click Create Manually, and then the format disk notice is displayed. 3. Click OK. Step 3 After creating RAID, the disks need to sync with each other to finish the process. For RAID5 and RAID6, you can select different working mode. ●...
Page 259 User‘s Manual Figure 4-254 Step 2 Click the icon behind a disk. Step 3 The New Hotspare interface is displayed. See Figure 4-255 (New hot spare (local) or Figure 4-256 (New hot spare (global). Figure 4-255 Figure 4-256 Step 4 You can select Local Hotspare or Global Hotspare.
Page 260: Record Estimate
User‘s Manual Click behind a hot spare disk to delete it. 1.12.9 Record Estimate Record estimate function can calculate how long you can record video according to the HDD capacity, and calculate the required HDD capacity according to the record period. Step 1 Select Main Menu >...
Page 261: Calculating Recording Time
User‘s Manual Figure 4-258 Step 3 Click Apply to save the settings. Then the system will calculate the time period that can be used for storage according to the channels settings and HDD capacity. Click Copy to to copy the settings to other channels. 1.12.9.1 Calculating Recording Time Step 1 On the Rec Estimate interface, click the By Space tab.
Page 262: Calculating Hdd Capacity For Storage
User‘s Manual Figure 4-260 1.12.9.2 Calculating HDD Capacity for Storage Step 1 On the Rec Estimate interface, click the By Time tab. The By Time interface is displayed. See Figure 4-261. Figure 4-261 Step 2 In the Time box, enter the time period that you want to record. In the Total Space box, the required HDD capacity is displayed.
Page 263 User‘s Manual Figure 4-262 Step 2 Configure the settings for the FTP settings parameters. See Table 4-81. Table 4-81 Parameter Description Enable Enable the FTP upload function. ● Select FTP type. FTP type ● FTP: Plaintext transmission. ● SFTP: Encrypted transmission (recommended) Server Address IP address of FTP server.
Page 264: Setting Iscsi
User‘s Manual Parameter Description Enter the length of the uploaded recorded video. ● If the entered length is less than the recorded video length, only a section of the recorded video can be uploaded. File Size ● If the entered length is more than the recorded video length, the whole recorded video can be uploaded.
Page 265: System
User‘s Manual Figure 4-263 Step 2 Set parameters. Table 4-82 Parameter Description Server Address Enter the server address of iSCSI server. Port Enter the port of iSCSI server, and the default value is 3260. Click Storage Path to select a remote storage path. Storage Path Each path represents an iSCSI shared disk and these paths are generated when created on the server...
Page 266: Rs232
User‘s Manual 1.13.2 RS232 After setting RS-232 parameters, the NVR can use the COM port to connect to other device to debug and operate. Step 1 Select MAIN MENU > SYSTEM > RS232. Step 2 The RS232 interface is displayed. See Figure 4-264. Figure 4-264 Step 3 Configure parameters.
Page 267: Security Status
User‘s Manual way. 1.14.1 Security Status Security scanning helps get a whole picture of device security status. You can scan user, service and security module status for detailed information about the security status of the device. Detecting User and Service Green icon represents a healthy status of the scanned item, and orange icon represents a risky status.
Page 268 User‘s Manual Figure 4-265 Figure 4-266 ● Configuration Security: When there’s a risk in the device configuration, the icon will be in orange to warn risk. You can click Details to see the detailed risk description. See Figure 4-267. Copyright © NSS Sp. z o.o.
Page 269: System Service
User‘s Manual Figure 4-267 Scanning Security Modules This area shows the running status of security modules. For details about the security modules, move mouse pointer on the icon to see the on-screen instructions. Scanning Security Status You can click Rescan to scan security status. 1.14.2 System Service You can set NVR basic information such as basic services, 802.1x and HTTPS.
Page 270: 259
User‘s Manual NTP Server is enabled. Table 4-84 Basic service parameters Parameter Description After enabling this function, the alarm triggered by the NVR can Mobile Push be pushed to a mobile phone. This function is enabled by Notifications default. If this function is enabled, the remote devices can be added through the CGI protocol.
Page 271: Https
User‘s Manual Figure 4-269 Step 2 Select the Ethernet card you want to certify. Step 3 Select Enable and configure parameters. See Table 4-85. Table 4-85 802.1x parameters Parameter Description ● PEAP: protected EAP protocol. Authentication ● TLS: Transport Layer Security. Provide privacy and data integrity between two communications application programs.
Page 272: Attack Defense
User‘s Manual Figure 4-270 Step 2 Enable HTTPS function. Step 3 (Optional) Enable Compatible with TLSv1.1 and earlier versions to allow protocol compatibility. Step 4 Click Certificate Management to create or import a HTTPS certificate from USB drive. For details about importing or creating a CA certificate, see "4.14.4 CA Certificate". Step 5 Select a HTTPS certificate.
Page 273 User‘s Manual Figure 4-271 Firewall Step 2 Select Enable to enable firewall. Step 3 Configure the parameters. See Table 4-86. Table 4-86 Parameters Parameter Description Mode can be configured when Type is Network Access. ● If Trusted Sites is enabled, you can visit device port successfully Mode with IP/MAC hosts in Trusted Sites.
Page 274: Account Lockout
User‘s Manual Parameter Description Enter MAC Address that is allowed or forbidden MAC Address When Type is MAC Address, they can be configured. Step 4 Click Apply to complete the settings. 1.14.3.2 Account Lockout Step 1 Select Main Menu > SECURITY > Attack Defense > Account Lockout. The Account Lockout interface is displayed.
Page 275: Sync Time-Whitelist
User‘s Manual Figure 4-273 Anti-Dos Attack 1.14.3.4 Sync Time-Whitelist The synchronization is only allowed with hosts in the trusted list. Step 1 Select Main Menu > SECURITY > Attack Defense > Sync Time-Whitelist. The Sync Time-Whitelist interface is displayed. See Figure 4-274. Figure 4-274 Sync Time-Whitelist Step 2 Select Enable to enable Sync Time-Whitelist function.
Page 276: Ca Certificate
User‘s Manual Table 4-88 Sync Time-Whitelist parameters Parameter Description You can add trusted hosts for time synchronization. Type Select IP address or IP segment for hosts to be added. Input the IP address of a trusted host. IP Address When Type is IP Address, it can be configured Input the start IP address of trusted hosts.
Page 277: Trusted Ca Certificate
User‘s Manual Parameter Description Organization This parameter is user defined. Organization Unit This parameter is user defined. Domain Name Input the domain name or IP address of the certificate. 3. Click Create. CA Application and Import Follow the on-screen instructions to finish CA application and import. See Figure 4-276. Figure 4-276 CA application and import Import Third-Party Certificate 1.
Page 278: Audio/Video Encryption
User‘s Manual Step 2 Click Install Trusted Certificate. The Create Certificate is displayed. See Figure 4-277. Figure 4-277 Creating certificate Step 3 Click Browse to select the certificate that you want to install. Step 4 Click Import. 1.14.5 Audio/Video Encryption The device supports audio and video encryption during data transmission.
Page 279: Security Warning
User‘s Manual Figure 4-278 Audio and video transmission Step 2 Configure parameters. See Table 4-91. Table 4-91 Audio and video transmission parameters Area Parameter Description Enables stream frame encryption by using private protocol. Enable There might be safety risk if this service is disabled. Encryption Private Use the default setting.
Page 280: Illegal Login
User‘s Manual Figure 4-279 Security Exception Step 2 Select Enable and configure parameters. See Table 4-92. Table 4-92 Security exception parameters Parameter Description The alarm device (such as lights, sirens, etc.) is connected to the Alarm-out Port alarm output port. When an alarm occurs, the NVR device transmits the alarm information to the alarm device.
Page 281 User‘s Manual Figure 4-280 Illegal Login Step 2 Select Enable and configure parameters. See Table 4-93. Table 4-93 Illegal login parameters Parameter Description The alarm device (such as lights, sirens, etc.) is connected to the Alarm-out Port alarm output port. When an alarm occurs, the NVR device transmits the alarm information to the alarm device.
Page 282: Account
User‘s Manual 1.15 Account You can manage users, user group and ONVIF user, set admin security questions. ● For the user name, the string max length is 31-byte, and for the user group, the string max length is 15-byte. The user name can only contain English letters, numbers and “_”, “@”, “.”. ●...
Page 283: Modify Password
User‘s Manual Figure 4-282 Step 3 Input the user name, password, select the group it belongs to from the drop-down list. Then you can check the corresponding rights for current user. See Table 4-94. Table 4-94 Parameter Description Username Enter a user name and password for the account. Password Confirm Password Re-enter the password.
Page 284 User‘s Manual The Modify User interface is displayed. See Figure 4-283. Figure 4-283 Step 2 Check the box to enable Modify Password function. Enter old password and then enter new password twice. ● Password/confirm password: The password ranges from 8 to 32 digitals. It can contain letters, numbers and special characters (excluding “'”,“"”,“;”,“:”,“&”) .
Page 285: Group
User‘s Manual Figure 4-284 Step 4 Click Back. 1.15.2 Group Step 1 Select Main Menu > ACCOUNT > Group. The Group interface is displayed. See Figure 4-285. Copyright © NSS Sp. z o.o.
Page 286 User‘s Manual Figure 4-285 Step 2 Click Add. The Add interface is displayed. See Figure 4-286. Step 3 Enter group name and then input some memo information if necessary. Check the box to select authorities. Figure 4-286 Step 4 Click OK. Copyright ©...
Page 287: Reset Password
User‘s Manual Click to modify the corresponding group information, click to delete the group. 1.15.3 Reset Password You can set security questions and answers. After you successfully answered security questions, you can reset admin account password. This function is for admin user only. Step 1 Select Main Menu >...
Page 288 User‘s Manual ● The default ONVIF user is admin. It is created after you initialize the NVR. ● For some series product, the ONVIF user password is modified when you are initializing the admin password. Step 1 Select Main Menu > ACCOUNT > ONVIF User. The ONVIF User interface is displayed.
Page 289: Output And Display
User‘s Manual Click to modify the corresponding user information, click to delete current user. 1.16 Output and Display 1.16.1 Display You can configure the display effect such as displaying time title and channel title, adjusting image transparency, and selecting the resolution. Step 1 Select Main Menu >...
Page 290: Tour
User‘s Manual Parameter Description Time Title/Channel Select the check box and the date and time of the system will be Title displayed in the preview screen. Image Select the check box to optimize the preview image edges. Enhancement Select the check box to display the SMD previews in the live view SMD Preview interface.
Page 291 User‘s Manual Figure 4-291 ● On the top right of the live view screen, use the left mouse button or press Shift to switch between (image switching is allowed) and (image switching is not allowed) to turn on/off the tour function. ●...
Page 292: Customized Display
User‘s Manual Step 3 Click Apply to save the settings. 1.16.3 Customized Display You can set customized video split mode. ● This function is for some series products. Refer to the actual product for detailed information. ● Device max. supports 5 customized videos. Step 1 Select Main Menu >...
Page 293 User‘s Manual ● After merge the window, system adopts the remaining window amount as the new name such as Split6. ● Select the window you want to merge (red highlighted), click to cancel the merge to restore the basic mode. ●...
Page 294: Audio
User‘s Manual Figure 4-294 1.17 Audio The audio function is to manage audio files and set schedule play function. It is to realize audio broadcast activation function. This function is for some series product only. 1.17.1 File Management You can add audio files, listen to audio files, rename and delete audio files, and configure the audio volume.
Page 295 User‘s Manual Figure 4-295 Step 2 Click Add. The Add interface is displayed. See Figure 4-296. NVR supports USB port to import audio file only. Figure 4-296 Step 3 Select the audio file and then click Import. Copyright © NSS Sp. z o.o.
Page 296: Audio Play
User‘s Manual System supports MP3 and PCM audio format. Step 4 Click OK to start importing audio files from the USB storage device. If the importing is successful, the audio files will display in the File Management interface. 1.17.2 Audio Play You can configure the settings to play the audio files during the defined time period.
Page 297: Broadcast
User‘s Manual 1.17.3 Broadcast System can broadcast to the camera, or broadcast to a channel group. Step 1 Select Mani Menu > AUDIO > Broadcast. The Broadcast interface is displayed. See Figure 4-298. Figure 4-298 Step 2 Click Add Group. The Add Group interface is displayed.
Page 298: Usb Device Auto Pop-Up
User‘s Manual ● On the broadcast interface, click to change group setup, click to delete group. ● After complete broadcast setup, on the preview interface and then click on the navigation bar, device pops up broadcast dialogue box. Select a group name and then click to begin broadcast.
Page 299: Shutdown
User‘s Manual You can add a USB keyboard through USB port, and it can input characters limited to soft keyboard. Figure 4-301 1.19 Shutdown ● When you see corresponding dialogue box "System is shutting down…" Do not click power on-off button directly. ●...
Page 300 User‘s Manual Figure 4-302 2. Select Shutdown. Draw the unlock pattern or input password first if you have no authority to shut down. See Figure 4-303 or Figure 4-304 Copyright © NSS Sp. z o.o.
Page 301 User‘s Manual Figure 4-303 Figure 4-304 ● Remote Control Press the power button on the remote for at least 3 seconds. ● Press the power button at the rear panel of the device. Copyright © NSS Sp. z o.o.
Page 302 User‘s Manual Auto Resume after Power Failure The system can automatically backup video file and resume previous working status after power failure. Copyright © NSS Sp. z o.o.
Page 303: Web Operation
User‘s Manual 2 Web Operation ● The interfaces in the Manual are used for introducing the operations and only for reference. The actual interface might be different dependent on the model you purchased. If there is inconsistency between the Manual and the actual product, the actual product shall govern. ●...
Page 304: Web Main Menu
User‘s Manual Figure 5-1 Step 2 Enter the user name and password. ● The default administrator account is admin. The password is the one that was configured during initial settings. To security your account, it is recommended to keep the password properly and change it regularly. ●...
Page 305 User‘s Manual Figure 5-2 Table 5-1 Icon Description Includes configuration menu through which you can configure camera settings, network settings, storage settings, system settings, account settings, and view information. None Displays system date and time. When you point to , the current user account is displayed. Click , select Logout, Reboot, or Shutdown according to your actual situation.
Page 306: Cluster Service
User‘s Manual Icon Description Includes eight function tiles: LIVE, PLAYBACK, AI, ALARM, POS, OPERATION, BACKUP, DISPLAY, and AUDIO. Click each tile to open the configuration interface of the tile. ● LIVE: You can perform the operations such as viewing real-time video, configuring channel layout, setting PTZ controls, and using smart talk and instant record functions if needed.
Page 307: Master Device
User‘s Manual can still work until you use the web to fix manually. During the whole process (the master device is working properly > master device is in malfunction > master device becomes working properly again), you can use this virtual IP to access the device all the time.
Page 308 User‘s Manual of the main device. Procedure Step 1 Click Manual Add. Figure 5-5 Step 2 Configure parameters. Table 5-2 Parameter Description Device Name This parameter is user defined. IP Address Enter the IP address of the NVR. Set the TCP port number of the server. The default vaule is 37777. Port You can view the current TCP port number in SETTING >...
Page 309: Slave Device
User‘s Manual Figure 5-6 2.4.3 Slave Device When you add the first slave device, the default IP is the device IP address that logins on the web. From SETTING > Cluster Service > Master Device, you can go to the following interface. See Figure 5-7.
Page 310: Cluster Control
User‘s Manual Figure 5-8 Step 4 Click OK. You can click to view the transfer information. 2.4.5 Cluster Control 2.4.5.1 Cluster Control From SETTING > Cluster Service > Cluster Control, you can go to the Cluster Control interface. It is to enable/disable cluster. See Figure 5-9. Figure 5-9 You can see the corresponding prompt if you successfully enabled cluster service.
Page 311: Cluster Log
User‘s Manual Figure 5-10 2.4.6 Cluster Log From SETTING > Cluster Service > Cluster Log, you can go to the Cluster Log interface. The Cluster log interface is shown as in Figure 5-11. Figure 5-11 Here you can search and view the Cluster log. Copyright ©...
Page 312: Glossary
User‘s Manual 3 Glossary ● DHCP: DHCP (Dynamic Host Configuration Protocol) is a network protocol. It is one of the TCP/IP protocol cluster. It is principally used to assign temporary IP addresses to computers on a network. ● DDNS: DDNS (Dynamic Domain Name Server) is a service that maps Internet domain names to IP addresses.
Page 313: Faq
User‘s Manual 4 FAQ Questions Solutions ● Input power is not correct. ● Power connection is not correct. ● Power switch button is damaged. ● Program upgrade is wrong. ● HDD malfunction or something wrong with HDD ribbon. NVR cannot boot up properly.
Page 314 User‘s Manual Questions Solutions ● Front panel PTZ error ● PTZ decoder setup, connection or installation is not correct. ● Cable connection is not correct. ● PTZ setup is not correct. ● PTZ decoder and NVR protocol is not compatible. NVR cannot control PTZ.
Page 315 User‘s Manual Questions Solutions ● Alarm setup is not correct. ● Alarm output has been open manually. Alarm signal cannot be ● Input device error or connection is not correct. disarmed. ● Some program versions may have this problem. Upgrade your system. ●...
Page 316 User‘s Manual Questions Solutions ● Make sure that the IPC has booted up. ● IPC network connection is right and it is online ● IPC IP is in the blacklist. ● The device has connected to the too many IPC. It I cannot connect to the IPC cannot transmit the video.
Page 317: Appendix 1 Cybersecurity Recommendations
User‘s Manual Appendix 1 Cybersecurity Recommendations Cybersecurity is more than just a buzzword: it’s something that pertains to every device that is connected to the internet. IP video surveillance is not immune to cyber risks, but taking basic steps toward protecting and strengthening networks and networked appliances will make them less susceptible to attacks.
Page 318 questions, it is suggested not to use those that can be easily guessed. 4. Enable Account Lock The account lock feature is enabled by default, and we recommend you to keep it on to User‘s Manual guarantee the account security. If an attacker attempts to log in with the wrong password several times, the corresponding account and the source IP address will be locked.
Page 319 14. Construct a Safe Network Environment In order to better ensure the safety of equipment and reduce potential cyber risks, we recommend: User‘s Manual ● Disable the port mapping function of the router to avoid direct access to the intranet devices from external network.
Page 320: Appendix 2 Hdd Capacity Calculation
User‘s Manual Appendix 2 HDD Capacity Calculation Calculate total capacity needed by each device according to video recording (video recording type and video file storage time). 1. According to Formula (1) to calculate storage capacity that is the capacity of each channel needed for each hour, unit Mbyte.
Page 321: Appendix 3 Compatible Network Camera List
User‘s Manual Appendix 3 Compatible Network Camera List Please note all the models in the following list for reference only. For those products not included in the list, please contact your local retailer or technical supporting engineer for detailed information. Appendix Table 3-1 Manufactur Video...
Page 322 User‘s Manual Manufactur Video Audio/Vide Model Version Protocol Encode √ NBN-921-P H264 ONVIF － NBC-455-12 H264 √ ONVIF － VG5-825 9500453 H264 √ ONVIF √ Bosch NBN-832 66500500 H264 ONVIF VEZ-211-IW H264 √ ONVIF － TEIVA NBC-255-P 15500152 H264 √ ONVIF VIP-X1XF H264...
Page 323 User‘s Manual Manufactur Video Audio/Vide Model Version Protocol Encode CP-RNC-TP cp20120821 H264 √ Private 20FL3C CP-RNP-12 cp20120828 √ H264 Private CP-RNC-DV cp20120821 H264 √ Private CP-RNC-DP cp20120821 √ H264 Private 20FL2C d20120214 ONVIF/Priva √ ICS-13 H264 vt20111123 ONVIF/Priva ICS-20W H264 √...
Page 324 User‘s Manual Manufactur Video Audio/Vide Model Version Protocol Encode H264、 ONVIF/Priva √ WV-SP508H － MPEG4 H264、 ONVIF/Priva WV-SP509H √ － MPEG4 H264、 ONVIF/Priva WV-SF332H 1.41 √ MPEG4 WV-SW316 H264、 ONVIF/Priva 1.41 √ MPEG4 WV-SW355 H264、 ONVIF/Priva √ 1.41 MPEG4 WV-SW352 H264、...
Page 325 User‘s Manual Manufactur Video Audio/Vide Model Version Protocol Encode 1.8.1-20110 IXSOLW 912-1.9082- H264 √ Private A1.6617 1.7.41.9111- IDE20DN H264 √ Private O3.6725 1.7.8.9310- √ D5118 H264 Private A1.5288 PELCO 1.6.13.9261- √ IM10C10 H264 Private O2.4657 DD4N-X 01.02.0015 MPEG4 √ Private √...
Page 326 User‘s Manual Manufactur Video Audio/Vide Model Version Protocol Encode ONVIF/Priva √ SNC-DH240 1.50.00 H264 SNC-DH240 ONVIF/Priva √ 1.73.01 H264 ONVIF/Priva √ SNC-CH260 1.74.01 H264 ONVIF/Priva SNC-CH280 1.73.01 H264 √ SNC-RH-12 ONVIF/Priva √ 1.73.00 H264 ONVIF/Priva SNC-RS46P 1.73.00 H264 √ ONVIF/Priva √...
Page 329 No reproduction of this manual, in whole or in part (with the exception of short quotes in critical articles or reviews), cannot be made without the written consent of NSS Sp. z o.o. NSS Sp. z o.o. ul. Modularna 11 (hala IV) 02-238 Warszawa Copyright ©...

BCS Line User Manual

Quick Links

Related Manuals for BCS Line

Summary of Contents for BCS Line
