BCS Line User Manual page 308

297
of the main device.
Procedure
Step 1 Click Manual Add.
Step 2 Configure parameters.
Parameter
Device Name
IP Address
Port
Username/Passwor
d
Step 3 Click OK.
Step 4 (Optional) Click
Copyright © NSS Sp. z o.o.
Figure 5-5
Table 5-2
Description
This parameter is user defined.
Enter the IP address of the NVR.
Set the TCP port number of the server. The default vaule is 37777.
You can view the current TCP port number in SETTING >
Network > Port
Enter the username and password of the NVR.
to view event occurrence time, name, operation and reason.
297
User's Manual
