User's Manual

1.1.4.6.1 Recording Schedule

After set schedule record, device can record video file according to the period you set here. For
example, the alarm record period is from 6:00–18:00 Monday, device can record alarm video
files during the 6:00–18:00.
All channels are record continuously by default. You can set customized record period and
record type.
Step 1 Click Next.
The Rec interface is displayed. See Figure 4-33.
Step 2 Select a channel from the drop-down list, you can set different record plans for
different channels. Select All if you want to set for all channels. See Table 4-9.
Parameter
Channel
Pre-record
Figure 4-33
Table 4-9
Description
In the Channel list, select a channel to record the video.
In the Pre-record list, enter the amount of time that you want to
start the recording in advance.
