User's Manual
Step 2 Select a channel, start time, end time, event type, and then click Search.
The search result is displayed.
Step 3 Click the picture that you want to play back.
You can also do the following operations to the recorded files.
● To back up the recorded files to the external storage device, select files, click
Backup, select the save path and file type, and then click Start.
● To lock the files to make it unable to be overwritten, select the files, and then click
Lock.
● To add a mark to the file, select the files and then click Add Tag.
● Go to the Attributes and Human Details to view detailed information.

1.7.1.4 Stereo Analysis

By drawing and setting the rules of stereo behavior analysis, the system will perform an alarm
linkage action when the video matches the detection rule. Types of events include: Human
approaching detection, fall detection, severe exercise detection, number of abnormal detection
and personnel retention detection.
● This feature requires access to a camera support stereo behavior analysis.
● Stereo analysis and IVS are mutually exclusive, and you need to apply smart plan in
advance.

1.7.1.4.1 People Approach Detection

When two people stays in the same detection area for a minimum duration or when the
distance between two people reaches the parameter setting, an alarm will be triggered.
Step 1 Select Main Menu > AI > Parameters > Stereo Analysis.
Figure 4-123
