Step 3 Select Channel, and then click Add.
Step 4 Select the Enable check box.
Step 5 Click to draw queuing rule and area.
Step 6 Click under the Parameters column, and then select alarm type to Queue
People No. Alarm or Queue Time Alarm.
Step 7 Click under the Trigger column, and configure alarm linkages.
Parameter
Period
Alarm Out
Latch
Alarm Upload
Send Email
Record Channel
Figure 4-162
Table 4-49
Description
Configure the period and in the set time range, the corresponding
configuration item will be linked to start the alarm.
The alarm device (such as lights, sirens, etc.) is connected to the
alarm output port. When an alarm occurs, the NVR device transmits
the alarm information to the alarm device.
When the alarm ends, the alarm extended for a period of time. The
time range is from 0 seconds to 300 seconds.
Select the check box. When an alarm occurs, the NVR device uploads
an alarm signal to the network (including the alarm center).
● This function is for some series products only.
● You need to set the alarm center first. For details, see "1.11.13
Alarm Center".
Select the check box. When an alarm occurs, the NVR device sends
an email to the set mailbox to notify the user.
You need to set the email first. For details, see "1.11.10 Email".
Select the check box and select the needed recording channel
(support multiple choices). When an alarm occurs, the NVR device
activates the channel for recording.
You need to enable intelligent recording and auto recording first. For
details, see"1.1.4.6 Schedule".
