1.11.14 Register

You can register the Device into the specified proxy server which acts as the transit to make it
easier for the client software to access the Device.
Step 1 Select Main Menu > NETWORK > Register.
The Register interface is displayed. See Figure 4-239.
Step 2 Configure the settings for the register parameters. See Table 4-77.
Function
Enable
Server IP Address
Port
Sub Service ID
Step 3 Click Apply to complete the settings.

1.11.15 Setting Switch

After setting Switch, when an IPC is connected to the PoE port, the system automatically
assigns the IP address to the IPC according to the set IP segment, and the NVR will
automatically connect to the IPC.
Figure 4-239
Table 4-77
Description
Enable the register function.
Enter the server IP address or the server domain that you want to
register to.
Enter the port of the server.
This ID is allocated by the server and used for the Device.
