Raid Manager - BCS Line User Manual

User's Manual
Parameter
Encrypt
3. Click OK.
The remote device information is displayed on the Added Device list.
Step 3 Click Next to complete the remote device registration.
Click
Once the multiple-sensor device has registered to the device system displays the
channel status on the Link info. See Figure 4-31. It shows one remote device has
occupied two channels: D1, D3.

1.1.4.5 RAID Manager

RAID (redundant array of independent disks) is a data storage virtualization technology that
combines multiple physical HDD components into a single logical unit for the purposes of data
redundancy, performance improvement, or both.
RAID function is for some series product only. Slight difference may be found on the user
interface.
Step 1 Select Main Menu > STORAGE > RAID > RAID.
Step 2 The RAID interface is displayed. See Figure 4-32.
Description
If the remote device is added through Onvif protocol, selecting
the Encrypt check box will provide encryption protection to the
data being transmitted.
To use this function, the HTTPS function should be enabled for
the remote IP camera.
to change the remote device information. Click
Figure 4-31
30
to delete remote device.
Copyright © NSS Sp. z o.o.
30
