159
Parameter
Picture Storage
Buzzer
Alarm Tone
Step 3 Click Apply.

1.7.2.11 Master-slave Tracking

Master-slave tracking refers to fisheye camera and speed dome linkage system. The fisheye
cameras serves as the main camera and captures panoramic videos; and the speed dome
serves as the slave camera and captures details of the video.
Prerequisites
● The monitoring areas of fisheye camera and speed dome should be the same area.
● Fisheye camera and speed dome should be added through private protocol.
This function is for select models only.
Procedure
Step 1 Select Main Menu > AI > Parameters > Master-Slave Tracking.
Step 2 Add monitoring area.
Copyright © NSS Sp. z o.o.
Description
Select the Snapshot check box to take a snapshot of the selected
channel.
To use this function, select Main Menu > CAMERA > Encode >
Snapshot, select Event in Type list.
Select the check box to activate the buzzer when an alarm
occurs.
Check the box and then select the corresponding audio file from
the drop-down list. System plays the audio file when the alarm
occurs.
Refer to "1.17.1 File Management" to add audio file first.
Figure 4-167
159
User's Manual
