User's Manual
Parameter
Audio
Compression
Sampling
Frequency
Step 5 Click OK.
Step 6 Click Apply.

1.2.6.2 Snapshot

You can set snapshot mode, image size, quality and interval.
Step 1 Select Main Menu > Camera > Encode > Snapshot
The Snapshot interface is displayed. See Figure 4-59.
Step 2 Configure parameters. See Table 4-18.
Parameter
Manual Snapshot
Channel
Table 4-17
Description
This function is enabled by default for main stream. You need to
manually enable it for sub stream 1. Once this function is enabled, the
recorded video file is composite audio and video stream.
In the Compressiont list, select a format: G711a, G711u, PCM, AAC.
In the Sampling Frequency list, you can select audio sampling rate.
Figure 4-59
Table 4-18
Description
In the Manual Snapshot list, select how many snapshots you want
to take each time.
In the Channel list, select the channel that you want to configure the
settings for.
