APR for Fiber Disconnect within an NE
Table 3-1 APR for High-Powered Fiber Connections within Network Elements (continued)
NE Type Fiber Jumper
Connection Points
OADM
•
port OUT DCF on
RPG Circuit Pack
•
port IN DCF on
OA(OADM LineIn)
Circuit Pack
•
port OUT SIG on RP
Circuit Pack
•
port IN DCM on
OA(OADM LineIn)
Circuit Pack
Note that these ports are
connected via the DCM
Circuit Pack
•
port OUT RPG on
RPG or RPG(DCF)
Circuit Pack
•
port IN RPG on RP
Circuit Pack
•
port OUTCORP on
RPG or RPG(DCF)
Circuit Pack
•
port INCORP on
OA(OADM LineOut)
....................................................................................................................................................................................................................................
365-575-783R1.1
Issue 1, June 2002
Associated Alarms
APR active: fiber disconnect
RPG to OA for Raman DCF pumps
DCM LOS: OA
of OA (alarmed)
APR active: OA DCF Raman
startup pumps
APR active: RPG Raman DCF
pumps (non-alarmed)
APR active: fiber disconnect
RPG to RP for Raman
counter-pumps
APR active: fiber disconnect
RPG to OA for Raman co-pumps
Lucent Technologies - Proprietary
See notice on first page
with aid = IN DCM
(non-alarmed).
Automatic Power Reduction (APR)
Components
Reduced in Power
Raman DCF
counter-pumps in
RPG(DCF)
Raman startup DCF
counter-pumps in
OA(OADM, line in)
and Raman DCF
counter pumps in
RPG(DCF) Circuit
Pack, if installed
Raman growth
counter-pumps in RPG
or RPG(DCF) Circuit
Pack
Raman co-pumps in
RPG or RPG(DCF)
Circuit Pack
