TAPs for PortOM_OD Alarm Group
TAP-310: Clear 'OMS LOS: add 100GHz at
OM (OADM 0GHz offset)'
....................................................................................................................................................................................................................................
6 - 1 1 2
IF...
NO
............................................................................................................................................................
CAUTION
SERVICE AFFECTING – this step could result in service
interruption.
Notify the person responsible for services supported by this optical
5
multiplex section to ensure that it is not utilized until the problem has
been resolved.
............................................................................................................................................................
Replace the fiber jumper between the OM(100 GHz) OUT_100G port
6
and the OM(OADM 0GHz offset) IN_100G port.
..........................................................................................................................................................
Examine the NE Alarm List
7
IF...
YES
NO
..........................................................................................................................................................
Connect a power meter to the OUT_100G port of the OM(100 GHz
8
offset) circuit pack. Is the the power from the OM(100 GHz offset) <
–16 dBm per channel?
IF...
Power < –16 dBm per
channel
Power > –16 dBm per
channel
............................................................................................................................................................
Replace the OM(100 GHz offset). For details, go to
9
Remove and/or Install Circuit Pack"
Lucent Technologies - Proprietary
See notice on first page
THEN...
Go to Step 16.
. Is the alarm condition still listed?
THEN...
Continue with Step
Go to Step 17.
THEN...
Continue with Step
Go to Step 12.
(7-20).
Trouble Clearing Tasks
8.
9.
"DLP-608:
365-575-783R1.1
Issue 1, June 2002
