Lucent Technologies LambdaXtreme Alarm Messages And Trouble Clearing Manual page 346

DLP-608: Remove and/or Install Circuit
Pack
....................................................................................................................................................................................................................................
7 - 2 6
Remove/Install an SCTL circuit pack
............................................................................................................................................................
Are you ready to remove or install an SCTL circuit pack?
1
IF...
remove
install
E S
N D O F T E P S
............................................................................................................................................................
Remove an SCTL circuit pack
............................................................................................................................................................
Push up on the bottom and down on the top locking clips to unlock
1
the circuit pack latches.
............................................................................................................................................................
Disengage the circuit pack by carefully and continuously pulling out
2
equally on the top and bottom latches.
DO NOT ROCK THE CIRCUIT PACK BACK AND FORTH
............................................................................................................................................................
Remove the circuit pack.
3
E S
N D O F T E P S
............................................................................................................................................................
Lucent Technologies - Proprietary
See notice on first page
Detail Level Procedures
THEN...
Continue with "Remove an SCTL
circuit pack" (7-26).
Go to "Install an SCTL circuit pack"
(7-27).
365-575-783R1.1
Issue 1, June 2002
