Tap-402: Clear 'Line Side: Wavewrapper Path Trace Identifier Mismatch - Lucent Technologies LambdaXtreme Alarm Messages And Trouble Clearing Manual

TAPs for OCHAN Alarm Group
TAP-402: Clear 'Line side: WaveWrapper path trace identifier
mismatch'
....................................................................................................................................................................................................................................
Overview
Procedure
....................................................................................................................................................................................................................................
6 - 1 2 0
This procedure is used to clear the
trace identifier mismatch
reads the optical channel path trace byte (0J3) in the optical channel
overhead. This condition indicates that the incoming optical channel
path trace message trace does not match the expected incoming
optical channel path trace message trace.
............................................................................................................................................................
Examine the
1 NE Alarm List
this alarm condition.
............................................................................................................................................................
Determine from the local office records what is the correct expected
2
received OCH path trace message for this signal.
..........................................................................................................................................................
Do the office records for the expected incoming optical channel path
3
trace message match the data in the expected incoming optical
channel path trace message listed in the report from
IF...
YES
NO
............................................................................................................................................................
At the CIT, click on the NE Alarm List icon to obtain an updated
4
report.
............................................................................................................................................................
Important! SERVICE AFFECTING - this step could result in
service interruption.
Trace the fiber jumper connected to the IN_wxyz port of the OT
5
identified in the
..........................................................................................................................................................
Do the office records indicate that the fiber jumper is connected to the
6
correct source?
Lucent Technologies - Proprietary
See notice on first page
Line side: WaveWrapper path
condition. LambdaXtreme
. Determine the AID of the OT reporting
THEN...
Continue with
Go to Step
column, back to the source.
AID
Trouble Clearing Tasks
™
Transport
Step 1?
Step 4.
9.
365-575-783R1.1
Issue 1, June 2002
