Stinger
®
ADSL Annex A Line Interface Module (LIM) Guide for LIMs with
ADSL2+ Capability
For software version 9.6.1
April 2004

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Stinger and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lucent Technologies Stinger

Summary of Contents for Lucent Technologies Stinger

  • Page 1 Stinger ® ADSL Annex A Line Interface Module (LIM) Guide for LIMs with ADSL2+ Capability For software version 9.6.1 April 2004...
  • Page 2 In rare instances, unauthorized individuals make connections to the telecommunications network through the use of access features. Trademarks Lucent, the Lucent logo, and all Lucent brand and product names are trademarks or registered trademarks of Lucent Technologies Inc. Other brand and product names are trademarks of their respective holders.

  • Page 3: Customer Service

    America for a menu of Lucent services. Or call +1 510-747-2000 for an operator. If you do not have an active services agreement or contract, you will be charged for time and materials. Stinger® ADSL Annex A LIM Guide for LIMs with ADSL2+ Capability...

  • Page 5: Table Of Contents

    Configuration for ADSL2+................2-18 Checking status of ADSL-DMT interface..............2-19 Checking status of the physical interface............2-20 Obtaining statistics about operations ............... 2-22 Displaying ADSL-DMT port status and nailed groups ........2-23 Stinger® ADSL Annex A LIM Guide for LIMs with ADSL2+ Capability...
  • Page 7 Figure 2-1 Noise margin parameters and power adjustments relationship..2-12 Figure 2-2 Future noise margins and dynamic rate adaptation relationship ..2-14 Figure 2-3 ADSL ATM LIM configuration............2-17 Stinger® ADSL Annex A LIM Guide for LIMs with ADSL2+ Capability...
  • Page 9 Additional features for LIMS with ADSL2+ capability ......1-1 Table 1-2 ADSL LIMs with ADSL2+ capability............ 1-2 Table 1-3 ADSL LIM status lights ................ 1-5 Table 2-1 Additional features for LIMS with ADSL2+ capability ......2-2 Stinger® ADSL Annex A LIM Guide for LIMs with ADSL2+ Capability...

  • Page 11: About This Guide

    About This Guide What is in this guide This guide provides general information about Stinger ADSL Annex A LIMs that have the capability to support the ADSL2+ protocols. It identifies the LIM models with ADSL2+ capability that are available for different Stinger chassis and describes how to configure and monitor them.

  • Page 12: Stinger Documentation Set

    Warning Warns of danger of electric shock. Warning Stinger documentation set The Stinger documentation set consists of the following manuals, which can be found at http://www.lucent.com/support and http://www.lucentdocs.com/ins: Read me first: – Edge Access and Broadband Access Safety and Compliance Guide. Contains important safety instructions and country-specific information that you must read before installing a Stinger unit.
  • Page 13 Installation and basic configuration: – Getting Started Guide for your unit. Shows how to install your Stinger chassis and hardware. This guide shows you how to use the command-line interface to configure and verify IP access and basic access security on the unit.

  • Page 15: Chapter 1 Overview

    TAOS 9.6.0 Installing an ADSL LIM Install an ADSL LIM in the same manner as other LIMs. See the Stinger Getting Started Guide for your unit for details. After installation, the module must be configured following the instructions in this guide.

  • Page 16: Module Specifications

    Physical dimensions Height: 15 inches (38.1cm). Width: 1.06 inches (2.69cm). Depth: 9 inches (22.8cm). STGR-LIM-AP-72: 110W (maximum) Power STGRRT-LIM-AP-72: 110W (maximum) STGR-LIM-AP-48: 76W (maximum) STGRRT-LIM-AP-48: 76W (maximum) STGRCR-LIM-AP-48: 22.9W Stinger® ADSL Annex A LIM Guide for LIMs with ADSL2+ Capability...

  • Page 17: Interpreting Lim Status Lights

    The front panel of the 48-port LIM has only 48 PORT lights at the bottom of the panel. All other lights are identical on the 72-port and 48-port LIMs. Stinger® ADSL Annex A LIM Guide for LIMs with ADSL2+ Capability...

  • Page 18: Figure 1-1 Stinger Adsl Lim (72-Port Lim Shown)

    (POST). When the module passes the POST and becomes operational, the ACTIVE light illuminates. Table 1-3 explains the status lights on an ADSL LIM Stinger® ADSL Annex A LIM Guide for LIMs with ADSL2+ Capability...

  • Page 19: Table 1-3 Adsl Lim Status Lights

    (One for have achieved frame synchronization, and the each port) local end of the ATM link has achieved cell delineation. If the light is not illuminated, the port is inactive. Stinger® ADSL Annex A LIM Guide for LIMs with ADSL2+ Capability...

  • Page 21: Configuration And Testing

    The TAOS software creates an al-dmt profile for each ADSL-DMT interface in a Stinger unit. The profiles are identified by the chassis and slot location of the LIM that provides them. One profile is created for each interface supported by the LIM in a specific slot.

  • Page 22: Overview Of The Al-Dmt Profile

    (upstream and downstream) of ADSL transmission. In the Stinger profiles, you set parameters to specify the data rate, signal quality and power, and data delay of the interface. The Stinger unit references these parameters in the training process.

  • Page 23: Line Activation And Dmt Parameters

    The Line-Config subprofile parameters configure an ADSL-DMT line. The parameters activate and set up the line and are shown with default values. The rate-adaptive and power parameters are described separately. Stinger® ADSL Annex A LIM Guide for LIMs with ADSL2+ Capability...
  • Page 24 Specifies the virtual path identifier (VPI) to use for virtual path (VP) switching on the LIM port. The default is 15. All other VPIs are used for virtual channel (VC) switching. call-route-info Not currently used Stinger® ADSL Annex A LIM Guide for LIMs with ADSL2+ Capability...
  • Page 25 This is the default for all protocols except G.lite. both—Not used. For related settings, see “Fast and interleaved bit-rate parameters” on page 2-9. Stinger® ADSL Annex A LIM Guide for LIMs with ADSL2+ Capability...
  • Page 26 The upstream and downstream start and end bins define the frequency ranges for upstream and downstream data. The frequency for a particular bin is defined as the bin number multiplied by 4.3125kHz. You must also make sure to adjust the Stinger® ADSL Annex A LIM Guide for LIMs with ADSL2+ Capability...

  • Page 27: Rate-Adaptive Mode Parameters

    The following parameters in the line-config subprofile, shown with default values, define how rate adaptation operates on the line: [in AL-DMT/{ any-shelf any-slot 0 }:line-config] rate-adapt-mode-up = automatic-at-startup rate-adapt-mode-down = automatic-at-startup Stinger® ADSL Annex A LIM Guide for LIMs with ADSL2+ Capability...

  • Page 28: Power-Level Parameters

    Its effective range is from 8dBm through 20dBm. max-power-spectral- Not used. density Note Downstream power is controlled by changing the settings of the max-aggr-power-level-down and psd-mask-down parameters. gain-default Not used. Stinger® ADSL Annex A LIM Guide for LIMs with ADSL2+ Capability...

  • Page 29: Fast And Interleaved Bit-Rate Parameters

    Setting min-bitrate-up Specifies the minimum bit rate for upstream traffic, from 0Kbps through 2016Kbps. The default value is 128Kbps. Note Not valid for the rate adaptation setting of operator-controlled. Stinger® ADSL Annex A LIM Guide for LIMs with ADSL2+ Capability...
  • Page 30 Only used for the rate adaptation setting operator-controlled. Note Setting this parameter to a value above 18016Kbps without installing the software license for ADSL2+ will have no effect, and will generate an error message. 2-10 Stinger® ADSL Annex A LIM Guide for LIMs with ADSL2+ Capability...

  • Page 31: Margin-Config Subprofile

    Noise margin parameters The margin-config subprofile contains the parameters that configure noise margins. Noise margins are defined in decibels (dB). A BER of 10 represents 0dB. The line Stinger® ADSL Annex A LIM Guide for LIMs with ADSL2+ Capability 2-11...

  • Page 32: Figure 2-1 Noise Margin Parameters And Power Adjustments Relationship

    Increase output power 0dB margin On many loops, the Stinger unit uses large power margins. To avoid excessive power margins, you can configure the Stinger unit with a maximum downstream noise margin value that it translates into a maximum power output value. The Stinger unit attempts to reduce the transmit power by a maximum of 12dB to achieve the desired maximum downstream noise margin.
  • Page 33 Lucent Technologies license for ADSL2+ is installed on the Stinger unit. When dynamic rate adaptation is in use, the downstream line adjusts its bit rate dynamically (it upshifts to increase its bit rate or downshifts to reduce it) on the basis of specified noise margins and intervals for which a noise level is maintained, provided that the maximum or minimum bit rate has not been reached.

  • Page 34: Figure 2-2 Future Noise Margins And Dynamic Rate Adaptation Relationship

    The following parameters configure dynamic rate adaptation for ADSL Annex-A LIMs with ADSL2+ capability. They are only valid when the Lucent Technologies license for ADSL2+ capability is installed on the Stinger unit, and the rate-adapt-mode parameter is set to dynamic. The following example illustrates their default settings.

  • Page 35: Configuring Call Control

    SPVC remains connected. Connections are broken only if the physical slot or line stops operating or is disabled by an administrator. By default, the Stinger unit monitors the physical line state of its interfaces and allows connections to be established only when the line state is fully connected.

  • Page 36: Adsl-Dmt Configuration Examples For Legacy Adsl

    The following examples are provided as a general guide for initial configuration of an ADSL-DMT interface. They illustrate settings that commonly work well for legacy ADSL protocols. You should modify the specific settings shown here to meet local requirements. 2-16 Stinger® ADSL Annex A LIM Guide for LIMs with ADSL2+ Capability...

  • Page 37: Figure 2-3 Adsl Atm Lim Configuration

    Configuration and Testing ADSL-DMT configuration examples for legacy ADSL In Figure 2-3, an ADSL-DMT interface in a Stinger unit is configured to support a rate-adaptive connection. Figure 2-3. ADSL ATM LIM configuration Ethernet ADSL modem POTS splitter Copper POTS pair...

  • Page 38: Examples For Configuration Of Adsl2+ Line Codes

    The following four examples illustrate line code options that are available with ADSL2+ capability to support line rates that are higher than legacy ADSL rates. The Lucent Technologies software license for ADSL2+ must be installed on the Stinger unit to successfully configure the parameters in the following examples.

  • Page 39: Checking Status Of Adsl-Dmt Interface

    Indicates how redundancy is activated. Valid values are inactive, manual and automatic. reason sparing-change- Indicates the time that the last change in redundancy state time occurred. Stinger® ADSL Annex A LIM Guide for LIMs with ADSL2+ Capability 2-19...

  • Page 40: Checking Status Of The Physical Interface

    = 91 num-sec-invalid = 0 operational-mode = g.lite Parameter Setting if-group-index Indicates the SNMP interface group index of the line. unit-type Indicates the operating mode (should always be COE). 2-20 Stinger® ADSL Annex A LIM Guide for LIMs with ADSL2+ Capability...
  • Page 41 The none setting indicates that the line is not operational. firmware-ver Indicates the version number of the ADSL modem firmware. ansi-adsl-ver Not used. hardware-ver Indicates the hardware version of the ADSL modem. Stinger® ADSL Annex A LIM Guide for LIMs with ADSL2+ Capability 2-21...

  • Page 42: Obtaining Statistics About Operations

    = 416772 incoming-cells = 92 outgoing-cells = 100 Parameter Description line-up-timer Indicates how long the interface has been up (days, hours, and minutes in {dd hh mm} format). 2-22 Stinger® ADSL Annex A LIM Guide for LIMs with ADSL2+ Capability...

  • Page 43: Displaying Adsl-Dmt Port Status And Nailed Groups

    All ADSL lines: (dvOp dvUpSt dvRq sAdm nailg) Line 1 4 1 } Idle 00151) Line 1 4 2 } Idle 00152) Line 1 4 3 } Idle 00153) Stinger® ADSL Annex A LIM Guide for LIMs with ADSL2+ Capability 2-23...
  • Page 44 1 4 8 } Idle 00158) Line 1 4 9 } Idle 00159) Line 1 4 10 } Idle 00160) Line 1 4 11 } Idle 00161) ..2-24 Stinger® ADSL Annex A LIM Guide for LIMs with ADSL2+ Capability...
