Overview
Features
Contents
....................................................................................................................................................................................................................................
4 - 2
The LambdaXtreme Transport System provides the following
performance monitoring features:
•
Full support of SONET and SDH parameters based on digital
parity checking of the given client SONET/SDH signal,
Supervisory signal or Wavewrapped signal
•
Support of analog parameters based on optical power
measurements for Optical Line, Optical Channels, and
Supervisory channel
•
Support for current 15-minute and 32 previous 15-min bins, as
well as current-day and 6 previous day registers for tracking and
reporting each analog and digital PM parameter
•
Initialization of current 15-minute and/or current day registers for
digital parameters at any time
•
User settable start time of day registers
•
Parameter baselining (automatic or user-initiated) for
provisionable analog PM parameters
•
User settable TCA/QOS thresholds for provisionable PM
parameters
•
User notification of TCA/QOS autonomous event warning
messages
•
Clearing of TCA/QOS events for analog parameters
•
Retrieval of TCA/QOS alarm messages via CIT and message
based EMS interfaces
•
Retrieval of PM data and threshold data per accumulation time
interval through the CIT or message-based OS interface
Performance Parameters
Optical Line Analog Performance Parameters
Optical Channel Analog Performance Parameters
OT Analog Parameters
OT Digital Performance Parameters
Supervisory Performance Parameters
Performance Data Processing
Thresholds
Lucent Technologies - Proprietary
See notice on first page
Performance Monitoring
4-3
4-4
4-5
4-7
4-8
4-10
4-11
4-18
