DLP-608: Remove and/or Install Circuit
Pack
....................................................................................................................................................................................................................................
7 - 2 4
............................................................................................................................................................
Dress the fiber(s) at the slot guide to ensure fiber(s) do not interfere
10
with the circuit packs insertion.
..........................................................................................................................................................
Was an OT installed?
11
IF...
YES
NO
............................................................................................................................................................
With a thumb on each latch, continue sliding the circuit pack with one
12
firm, continuous motion until the latches are fully engaged and the
clips are in the locked position.
E S
N D O F T E P S
............................................................................................................................................................
Remove an NCTL circuit pack
............................................................................................................................................................
1 Press the green Reset button next to the FlashDisk.
............................................................................................................................................................
Wait until the green LED starts to blink steadily.
2
............................................................................................................................................................
Remove the FlashDisk.
3
............................................................................................................................................................
Push up on the bottom and down on the top locking clips to unlock
4
the circuit pack latches.
............................................................................................................................................................
Disengage the circuit pack by carefully and continuously pulling out
5
equally on the top and bottom latches.
DO NOT ROCK THE CIRCUIT PACK BACK AND FORTH
............................................................................................................................................................
Remove the circuit pack.
6
Lucent Technologies - Proprietary
See notice on first page
Detail Level Procedures
THEN...
STOP! YOU HAVE COMPLETED
THIS PROCEDURE.
Go to Step 12 (for OA, OD, OMON,
OM, RP, RPG, or SUPVY).
