TAP-503: Clear Drop Side Incoming LOF Failures

....................................................................................................................................................................................................................................
Overview
Procedure
....................................................................................................................................................................................................................................
365-575-783R1.1
Issue 1, June 2002
This procedure explains how to address one of the following incoming
signal failures:
•
Drop side OC-48/STM-16 LOF failure
•
Drop side OC-192/STM-64 LOF failure
These alarms are raised at the OUT_DROP port of the OT circuit
pack when the OT fails to detect the expected SONET/SDH frame
structure. This is an indication that there is problem with the upstream
OT.
Important! OC-192/STM-64 is associated with the 10G ADD DROP
OT. OC-48/STM-16 is associated with the MUX OT.
............................................................................................................................................................
At the CIT NE Alarm List
1
AID of the OT with the failure.
............................................................................................................................................................
Determine the OT frequency associated with the identified AID.
2
............................................................................................................................................................
Identify the NE of the corresponding upstream OT circuit pack.
3
............................................................................................................................................................
Log into the identified NE.
4
..........................................................................................................................................................
Are any alarms reported in this NE, associated with the identified
5
OT?
IF...
YES
NO
............................................................................................................................................................
Clear the alarms. Refer to
6
Lucent Technologies - Proprietary
See notice on first page
, examine the AID column and record the
THEN...
Continue with Step 6
Go to Step 9.
Appendix A, "Alarm/Condition
Trouble Clearing Tasks
List".
