TAP-604: Clear 'EMS link failure'

....................................................................................................................................................................................................................................
Overview
Procedure
....................................................................................................................................................................................................................................
6 - 1 5 8
This procedure explains how to clear the
condition.
This alarm condition occurs when there is a loss of signal at the
provisioned EMS port on the SIO circuit pack.
The failure can be caused by any of the following conditions:
•
A disconnected cable at the EMS port
•
A faulty cable between the EMS port and the nearby DCN device
•
A faulty DCN device (for example, the nearby router)
............................................................................................................................................................
Consult the office records to determine whether the EMS port should
1
be provisioned.
IF...
YES
NO
............................................................................................................................................................
At the CIT, set the EMS port state to
2
STOP! YOU HAVE COMPLETED THIS PROCEDURE.
............................................................................................................................................................
Remove the cover of shelf A1–3. All connections can be accessed
3
from the front. For details, refer to
Cover" (7-17).
............................................................................................................................................................
Inspect the connection to the EMS port on the SIO circuit pack, and
4
fix any problems.
..........................................................................................................................................................
Is the
5
EMS link failure
IF...
YES
Lucent Technologies - Proprietary
See notice on first page
EMS link failure
THEN...
Go to Step 3.
Continue with Step
Inactive .
"DLP-607: Remove/Install Front
alarm condition still listed?
THEN...
Continue with Step
Trouble Clearing Tasks
alarm
2.
6.
