Tap-203: Clear 'Apr Active: Line - Lucent Technologies LambdaXtreme Alarm Messages And Trouble Clearing Manual

TAPs for PortOA_RP and LINE Alarm
Groups

TAP-203: Clear 'APR active: line'

....................................................................................................................................................................................................................................
Overview
Procedure
....................................................................................................................................................................................................................................
6 - 5 2
This procedure is used to clear the
™
LambdaXtreme
safe levels if an incoming loss of signal is detected. The
condition is generated when the Raman co- and/or counter-pump
line
powers have been reduced to safe levels as a result of SUPV and/or
DWDM loss of signal detection in OA and RP circuit packs. This
condition will be present as long as OTS LOS and/or OSC LOS
(opposite direction to optical channels) are present. The loss of
DWDM and SUPV signals is caused by a fiber cut in the outside
plant.
It is necessary to look at the upstream nodes to determine whether the
reported APR condition is caused by a problem in the local node or if
it has propagated to to this node from a problem further upstream.
Once you have identified the node furthest upstream that is reporting
an
APR active: line
source of the problem located between the second and third
downstream nodes. See
cut" (3-5).
When the incoming loss of signal is repaired, LambdaXtreme
Transport will resume normal operation and the APR active condition
will clear.
............................................................................................................................................................
Examine the
1 NE Alarm List
(opposite direction to optical channels)
present in the NE at the
IF...
YES
NO
............................................................................................................................................................
Proceed to "TAP-201: Clear 'OTS LOS' and/or 'OSC LOS (opposite
2
direction to optical channels)'"
..........................................................................................................................................................
Is the
3
APR active: line
Lucent Technologies - Proprietary
See notice on first page
APR active: line
Transport reduces the circuit pack output power to
alarm condition, you can expect to find the
Figure 3-2, "APR Active Zone for single-fiber
. Are either the
Source Address ID
THEN...
Continue with
Go to Step
(6-45).
condition still listed?
Trouble Clearing Tasks
condition.
APR active:
or
OTS LOS OSC LOS
alarm conditions
?
Step 2.
4.
365-575-783R1.1
Issue 1, June 2002
