DLP-605: Install/Remove Apparatus Blank
....................................................................................................................................................................................................................................
Overview
Procedure
....................................................................................................................................................................................................................................
7 - 1 0
This procedure describes how to install or remove an apparatus blank.
............................................................................................................................................................
Is an apparatus blank to be installed or removed?
1
IF...
To be installed
To be removed
............................................................................................................................................................
Position the apparatus blank vertically with its extended release tabs
2
facing towards you.
............................................................................................................................................................
Insert the apparatus blank into the circuit pack slot and push it in until
3
the upper and lower release tabs snap onto the shelf cross-support
channels.
............................................................................................................................................................
STOP! YOU HAVE COMPLETED THIS PROCEDURE.
4
............................................................................................................................................................
Push down on the upper release tab and pull up on the lower release
5
tab to release the apparatus blank from the shelf cross-support
channels.
............................................................................................................................................................
Slide the apparatus blank from the slot.
6
E S
N D O F T E P S
.........................................................................................................................................................................................................................................................
Lucent Technologies - Proprietary
See notice on first page
Detail Level Procedures
THEN...
Continue with Step 2.
Go to Step 5.
