DLP-602: Test LEDs on Circuit Packs

....................................................................................................................................................................................................................................
Overview
Procedure
....................................................................................................................................................................................................................................
365-575-783R1.1
Issue 1, June 2002
Use the procedure below to test the LEDs on the circuit pack
faceplates.
............................................................................................................................................................
Remove the appropriate shelf cover(s). All LEDs are visible from the
1
front. For details, go to
(7-17).
............................................................................................................................................................
At the CIT, select
2
and shelf, then click on the select button.
Important! Requirement: All LEDs are lighted for 10 seconds, off
for 10 seconds for each iteration, then they return to their normal
condition.
............................................................................................................................................................
Select the number of iterations and then click on the Start button.
3
..........................................................................................................................................................
Did the LED(s) of interest operate as indicated above?
4
IF...
YES
NO
............................................................................................................................................................
Reinstall the shelf cover(s). For details, go to
5
Remove/Install Front Cover"
............................................................................................................................................................
STOP! YOU HAVE COMPLETED THIS PROCEDURE.
6
............................................................................................................................................................
At the CIT, select
7
shelf, and select 3 iterations for the test.
..........................................................................................................................................................
Did the same circuit pack LED consistently fail the LED test?
8
Lucent Technologies - Proprietary
See notice on first page
"DLP-607: Remove/Install Front Cover"
FAULT-Test-LED then select the appropriate bay
THEN...
Continue with
Go to Step
(7-17).
Fault -Test-LED then select the appropriate bay,

Detail Level Procedures

Step 5.
7.
"DLP-607:
7 - 5
