DLP-608: Remove and/or Install Circuit
Pack
....................................................................................................................................................................................................................................
7 - 2 2
WARNING
Unterminated optical connectors may emit invisible laser
radiation. Eye damage may occur if beam is viewed directly
or with improper optical instruments. Avoid direct exposure
to the beam.
Remove an OA, OD OMON, OM, OT, RP, RPG, or SUPVY circuit
pack.
............................................................................................................................................................
Disengage the circuit pack from the appropriate shelf as follows:
1
1. Push up on the bottom and down on the top locking clips to
unlock the circuit pack latches.
2. Disengage the circuit pack by carefully and continuously pulling
out equally on the top and bottom latches.
3. Remove the fiber(s) from the appropriate port(s) listed for the
circuit pack(s) in
4. Drape the removed fibers so as not to interfere with the circuit
pack(s) removal.
5. Carefully slide the circuit pack out of the slot guides to remove it
from the shelf. DO NOT ROCK THE CIRCUIT PACK BACK
AND FORTH.
..........................................................................................................................................................
Are you to install another circuit pack in this slot?
2
IF...
YES
NO
............................................................................................................................................................
Important! When a slot has no circuit pack in place an apparatus
blank must be installed in lieu of the circuit pack to provide the
correct level of cooling.
3 Install an apparatus blank in each vacant slot. For details, go to
"DLP-605: Install/Remove Apparatus Blank"
E S
N D O F T E P S
............................................................................................................................................................
Lucent Technologies - Proprietary
See notice on first page
Table 7-1, "Circuit Packs and Ports"
THEN...
Go to Step 2
OMON, OM, OT, RP, RPG, or SUPVY
circuit pack."
Continue with
Detail Level Procedures
(7-29).
of "Install an OA, OD,
(7-23).
Step 3.
(7-10).
