TAPs for PortOM_OD Alarm Group
TAP-302: Clear 'OMS LOS: 0GHz and 100GHz offset at OA
(preamp)' and 'OMS LOS: 50GHz and 150GHz offset at OA
(preamp)'
....................................................................................................................................................................................................................................
Overview
Procedure
....................................................................................................................................................................................................................................
365-575-783R1.1
Issue 1, June 2002
Use this procedure to clear the following alarm conditions:
•
OMS LOS: 0GHz and 100GHz offset at OA (preamp)
•
OMS LOS: 50GHz and 150GHz offset at OA (preamp)
These alarms are raised at the OA(Preamp) circuit pack when there is
a total loss of signal at it's IN_SIG port. This indicates an Optical
Multiplex Section (OMS) loss of signal (LOS) between the OUT ports
of the RP circuit pack and the IN_SIG port of the associated
OA(Preamp).
OMS LOS: 0GHz and 100GHz offset at OA (preamp)
when a LOS is detected at the IN_SIG port of the OA(Preamp)
associated with the 0/100 GHz channels at 10G and 40G End
Terminals.
OMS LOS: 50GHz and 150GHz offset at OA (preamp)
when a LOS is detected at the IN_SIG port of the OA(Preamp)
associated with the 50/150 GHz channels in the 10G End Terminal.
............................................................................................................................................................
At The CIT, examine the
1
OA(Preamp).
............................................................................................................................................................
Remove the cover from the shelf identified in
2
can be accessed from the front. For details, go to
Remove/Install Front Cover"
............................................................................................................................................................
CAUTION
SERVICE AFFECTING – this step could result in service
interruption.
Visually inspect the incoming signal fiber between the OUT port of
3
the RP and the IN_SIG port of the OA(Preamp). Correct any
Lucent Technologies - Proprietary
See notice on first page
NE Alarm List , and identify the AID of the
Step
(7-17).
Trouble Clearing Tasks
is raised
is raised
1. All connections
"DLP-607:
6 - 8 1
